Newport Wood & Glass L Desk
Model # JCS110605-D
ADULT ASSEMBLY REQUIRED DUE TO THE PRESENCE OF SMALL PARTS, SHARP
POINTS, SHARP EDGES AS RECEIVED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our website 24 hours a day, 7 days a week for product assistance at:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Mfg., Inc.
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
1-866-942-5362
Page 1
LOT NUMBER:
DATE PURCHASED: /
Factory No. 33-10944
/
Advertisement
Related Manuals for Whalen JCS110605-D
Summary of Contents for Whalen JCS110605-D
- Page 1 LOT NUMBER: DATE PURCHASED: / Newport Wood & Glass L Desk Model # JCS110605-D ADULT ASSEMBLY REQUIRED DUE TO THE PRESENCE OF SMALL PARTS, SHARP POINTS, SHARP EDGES AS RECEIVED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased.
- Page 2 Model # JCS110605-D Parts and Hardware List Please read completely through the instructions and verify that all listed parts are present before beginning assembly. A- Desk Leg (1) B- Return Leg (1) C- Desk Top Frame (1) D- Desk Bottom Stretcher (1)
- Page 3 Model # JCS110605-D Assembly Instructions NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. 1. Unpack the unit and confirm that you have all the hardware and required parts.
- Page 4 Model # JCS110605-D Assembly Instructions 4. Fasten the Desk Bottom Stretcher (D) to the bottom rail of Desk Leg (A) by inserting one 3-1/8” Bolt (5) through the countersunk hole on the leg into place, as shown . 5. Align and attach the Desk Top Frame (C) to the top rail of the Desk Leg (A) and the Back Support (H) using four 1-1/4”...
- Page 5 Model # JCS110605-D Assembly Instructions 6. Fasten the Return Bottom Stretcher (G) to the bottom rail of the Return Leg (B) by inserting one 3-1/8” Bolt (5) through the countersunk hole on the leg into place, as shown . 7. Align and attach Return Top Back Stretcher (F) to the back socket on the top rail of the Return Leg (B) using one 3/4”...
- Page 6 Model # JCS110605-D Assembly Instructions 9. Align and attach last assembly to the Desk Top Frame (C) and the Desk Bottom Stretcher (D), as shown. Insert and screw two 1-1/4” Bolts (2) with Washers (6 and 7) through the pre-drilled holes on the Desk Top Frame (C) into the Return Top Back Stretcher (F).
- Page 7 Model # JCS110605-D Assembly Instructions 11. Align and attach four Metal Bars (I) to the backside of the assembled unit for extra support using eight 3/4” Bolts (1) and tighten with the provided Allen Wrench. 3/4” Bolt (8 used in this step) ①...
- Page 8 Model # JCS110605-D Assembly Instructions 12. Screw 16 Glass Risers (9) all the way into the top sockets of the assembled unit. 13. Set the Desk Top (J) and the Return Top (K) onto place with the black side of glass down, as shown.
- Page 9 Model # JCS110605-D Assembly Instructions 14. Go back and tighten all bolts with the enclosed Allen Wrench. Cover the countersunk hole on Desk Leg (A) and Return Leg (B) by inserting the provided Wood Plugs (8). Gently tap the Wood Plugs with a rubber mallet to ensure they are fully seated.
-
Page 10: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
