Wesleyan Drop Lid Secretary
Model # JCS20501-B
ADULT ASSEMBLY REQUIRED DUE TO THE PRESENCE OF SMALL PARTS, SHARP
POINTS, SHARP EDGES AS RECEIVED. 2 PEOPLE RECOMMENDED.
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Mfg., Inc.
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
1-866-942-5362
Page 1
LOT NUMBER:
DATE PURCHASED: /
Factory No. 16015
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the Wesleyan Drop Lid Secretary and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Whalen Wesleyan Drop Lid Secretary

Summary of Contents for Whalen Wesleyan Drop Lid Secretary

  • Page 1 LOT NUMBER: DATE PURCHASED: / Wesleyan Drop Lid Secretary Model # JCS20501-B ADULT ASSEMBLY REQUIRED DUE TO THE PRESENCE OF SMALL PARTS, SHARP POINTS, SHARP EDGES AS RECEIVED. 2 PEOPLE RECOMMENDED. If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased.
  • Page 2 4. Plug the Cam Lock Cover into the cross slot of the Cam Locks to conceal the cam. You are now ready to assemble the KD unit. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 2 Factory No. 16015...
  • Page 3 PL- Left Bottom Molding (1) PL- Right Bottom Molding (1) QL- Left Slide Support (1) QR- Right Slide Support (1) QM- Middle Slide Support (1) 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 3 Factory No. 16015...
  • Page 4 X- Drop Lid Support (2) (1) Small Cam Lock (38+1 extra) (2) Large Cam Lock (36+1 extra) (3) Long Cam Bolt (58+2 extra) 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 4 Factory No. 16015...
  • Page 5 Touch-up Pen (1) Tipping Restraint Hardware Kit (2) (Included in plastic bag) Tools required: Allen Wrench (provided), Phillips screwdriver and Hammer (not provided). 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 5 Factory No. 16015...
  • Page 6 4. Slide one Drawer Bottom Panel (V4) into the grooves between the Drawer Side Panels (V2 and V3) until fully inserted into Drawer Front (V). Make sure that the finished surface is up. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 6 Factory No. 16015...
  • Page 7 6. Attach one Knob (21) to the outside of the Drawer Front (V) using the provided Knob Bolt (22). 7. Repeat the same process to assemble the other utility drawer. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 7 Factory No. 16015...
  • Page 8 Panels (U2) on a level and protective surface with the holes facing up. Securely screw 16 Short Cam Bolts (24) into the designated small holes, as shown in the illustration. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 8 Factory No. 16015...
  • Page 9 Fasten the Pigeon Cube Inner Panel (U2) to the Pigeon Cube Bottom Panel (U3) by engaging two Small Cam Locks (1). As shown below. 13. Repeat the same procedure to assemble the other pigeon cube. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 9 Factory No. 16015...
  • Page 10 17. Position the Pigeon Cube Top Panel (U) onto the inserted Wood Dowels (5) making sure the back edges are even with each other. Attach the Top Panel (U) in place by engaging eight Small Cam Locks (1). 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 10 Factory No. 16015...
  • Page 11 NOTE: We recommend attaching back panel with the Ring Shank Nails at the corners first. 20. Plug 8 Cam Lock Covers with Rod (18) onto the visible Cams Locks to conceal the Cam Locks. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 11 Factory No. 16015...
  • Page 12 23. Secure screw the Long Cam Bolts (3) into the designated small holes on the Left and Right Side Posts (BP and CP), as shown in the illustration. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 12 Factory No. 16015...
  • Page 13 Flat Washers (8). As shown. Tighten the bolts with the provided Allen Wrench. 28. Repeat the same procedure to attach the Right Bottom Molding (PR) to the Right Side Panel (C). 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 13 Factory No. 16015...
  • Page 14 Support (T) respectively with three #6 x 1/2” Screws (9) per slide track. As shown below. Make sure that the slide opening faces the front of the unit. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 14 Factory No. 16015...
  • Page 15 32. Securely screw the Long Cam Bolts (3) into the designated small holes on the Left and Right Side Panels (B and C), as shown in the illustration. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 15 Factory No. 16015...
  • Page 16 M8 x 30 mm Wood Dowels (4) in each, as shown. Make sure that the finished edges point towards the same direction. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 16 Factory No. 16015...
  • Page 17 Lid Support Arm. As shown. 39. Repeat the same procedure to attach the other Drop Lid Support (X) to the Left Lid Support Arm (SL). SL/SR 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 17 Factory No. 16015...
  • Page 18 #6 x 5/8” Screws (13). 43. Securely screw two Long Cam Bolts (3) into the designate small holes on the Drawer Housing Bottom Panel (E), as shown. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 18 Factory No. 16015...
  • Page 19 Panel (F) and then press them together. Make sure the top surfaces are flush with each other. Fasten the Front Stretcher (G) to the Bottom Panel (F) by engaging three Large Cam Locks (2). 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 19 Factory No. 16015...
  • Page 20 48. Turn the assembled base upright. 49. Securely screw four Long Cam Bolts (3) into the designate small holes on the Bottom Panel (F), as shown. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 20 Factory No. 16015...
  • Page 21 (12), as shown. Make sure that the Wood Screw cutout of the Lower Partition Panel (J) against the Right Back Panel (LR). 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 21 Factory No. 16015...
  • Page 22 (E) and the Bottom Panel (F) with 4 Large Cam Locks (2). As shown. 56. Repeat the same procedure to attach the Left Side Panel (B) at the other end. IL/IR 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 22 Factory No. 16015...
  • Page 23 And then attach the Magnetic Catches (15) in place using two #6 x 5/8” Screws (13) in each. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 23 Factory No. 16015...
  • Page 24 67. Repeat the same procedure to install the Left Door (NL) to the Left Side Post (BP). Open and close the doors to make sure they are aligned and shut correctly. If necessary, adjust the screws for a good fit. NL/NR NL/NR 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 24 Factory No. 16015...
  • Page 25 69. Pull both Lid Support Arms (SL and SR) all the way out and stick one Rubber Pad (23) on the top of each Lid Support Arm front trim as a bumper, as shown below. SL/SR 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 25 Factory No. 16015...
  • Page 26 73. Pull both Drop Lid Support (X) all the way forward and secure the end metal bracket onto the Drop Lid (M) with two #6 x 1/2” Screws (9) in each, using the pilot holes as a guide. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 26 Factory No. 16015...
  • Page 27 Shelf (L) onto the Shelf Pins (25) making sure the end notches of the Adjustable Shelf fit onto the Shelf Pins properly. 76. Plug the Cam Lock Covers (17 and 18) onto the visible Cams Locks to conceal the Cam Locks. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 27 Factory No. 16015...
  • Page 28 Tools required: Phillips screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 28 Factory No. 16015...

  • Page 29: Care And Maintenance

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
