If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Jasper L Desk
Model # ODUS-JLDHCV
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2020-07-17
1-866-942-5362
Rev. 0001-A
LOT NUMBER:
DATE PURCHASED: /
/

Advertisement

loading

Related Manuals for Whalen ODUS-JLDHCV

Summary of Contents for Whalen ODUS-JLDHCV

  • Page 1 LOT NUMBER: DATE PURCHASED: / Jasper L Desk Model # ODUS-JLDHCV ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...

  • Page 2: Special Note

    M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Jasper L Desk MODEL # ODUS-JLDHCV MAXIMUM LOAD 100 lb.
  • Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4, 5 and 6 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Desk Glass Top B- Return Glass Top C- Left Top Panel ( Qty. 1) ( Qty. 1) ( Qty.
  • Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. P- Return Shelf Support Q- Large Leg R- Small Leg ( Qty. 1) ( Qty. 1) ( Qty. 1) S- Desk Back Upper Stretcher T- Desk Front Upper Stretcher U- Return Back Upper Stretcher...
  • Page 6 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (10) M6 x 35 mm Zinc Bolt (11) M6 x 50 mm Zinc Bolt (12) Zinc Lock Washer (Qty.
  • Page 7 Assembly Instructions NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch.
  • Page 8 Assembly Instructions 4. Glue four 30 mm Wood Dowels (3) to the Left Back Panel (F) and attach it to the previous assembly by engaging four Cam Locks (1) (Refer to page 3 on Cam Lock system operation supplement). 5. Fasten the Left Front Panel (E) to the front end of Left Bottom Panel (D) using two 30 mm Wood Dowels (3) and one Cam Lock (1).
  • Page 9 Assembly Instructions 8. Flip around the assembled side frame. 9. With the pilot holes as a guide, fasten two Square Metal Brackets (17) at the joints of Left Bottom Panel (D) by using four 20 mm Screws (14) per bracket. 10.
  • Page 10 Assembly Instructions 12. Repeat the same procedure to form the Right Side Frame.
  • Page 11 Assembly Instructions 13. Securely screw the Self-tapping Cam Bolts (2) into the designated small holes on the Fixed Shelves (M and O), Legs (Q and R) and Desk Shelf Support (N) as shown. 14. Glue two 30 mm Wood Dowels (3) into the inner holes of the Return Shelf Support (P) and attach it to the Return Fixed Shelf (O) by engaging three Cam Locks (1).
  • Page 12 Assembly Instructions 16. Using the pilot holes as a guide, attach two Straight Metal Brackets (19) to the Desk Fixed Shelf (M) with four 12 mm Screws (16). 17. Align and attach the previous assembly to the Small Leg (R) with two 30 mm Wood Dowels (3) and three Cam Locks (1) as shown.
  • Page 13 Assembly Instructions 18. Align and attach the Large Leg (Q) to the Small Leg (R) and Desk Fixed Shelf (M) with three 30 mm Wood Dowels (3) and five Cam Locks (1). 19. Fasten one Back Lower Stretcher (W) to the Large Leg (Q) using two 15 mm Black Bolts (6) and two Black Washers (8 and 9).
  • Page 14 Assembly Instructions 20. Flip the previous assembled unit upside down. 21. Align and attach the Desk Fixed Shelf and Support (M and N) to the Left Side Panel (G) by using two 30 mm Wood Dowels (3) and three Cam Locks (1). 22.
  • Page 15 Assembly Instructions 24. Align and attach the Return Fixed Shelf and Support (O and P) to the Right Side Panel (L) with two 30 mm Wood Dowels (3) and three Cam Locks (1). 25. Secure the Return Fixed Shelf (O) to the Right Side Panel (L) by attaching one Metal Bracket (18) at the bottom joints with four 15 mm Black Bolts (6) and four Black Washers (8 and 9).
  • Page 16 Assembly Instructions 26. Fasten the other Back Lower Stretcher (W) to the Right Back Panel (K) with two 15 mm Black Bolts (6) and two Black Washers (8 and 9). 27. Glue two 40 mm Wood Dowels (4) into the end holes of the Return Fixed Shelf (O) and one 30 mm Wood Dowel (3) into the end hole of the Return Shelf Support (P).
  • Page 17 Assembly Instructions 30. Attach the Return Fixed Shelf (O) to the Straight Metal Brackets (19) with four 12 mm Screws (16). 20/21 31. Ask for assistance to flip around the assembled unit upright. 32. Fasten the Left and Right Metal Brackets (20 and 21) to the upper corners of assembled side frames by using two 15 mm Black Bolts (6) and two Black Washers (8 and 9) per bracket.
  • Page 18 Assembly Instructions 33. Screw the Regular Cam Bolts (5) into the side threaded sockets on the Back Upper Stretchers (S and U) as shown. 34. Align and attach the Desk Back Upper Stretcher (S) to the Large Leg (Q) by using two Cam Locks (1). You may need to adjust the height of Regular Cam Bolts (5) when assembling.
  • Page 19 Assembly Instructions 36. Repeat the same procedure to attach the Return Back Upper Stretcher (U) to the Small Leg (R) and the installed Left Metal Bracket (20). 37. Insert two 50 mm Zinc Bolts (11) with the Zinc Flat Washers (13) through the drilled holes on the Return Back Upper Stretcher (U) and securely screw into the Desk Back Upper Stretcher (S).
  • Page 20 Assembly Instructions 38. Align and attach the Desk Front Upper Stretcher (T) to the Return Back Upper Stretcher (U) by using two 50 mm Zinc Bolts (11) and two Zinc Flat Washers (13). 39. Fasten the Desk Front Upper Stretcher (T) to the installed Left Metal Bracket (20) with two 15 mm Black Bolts (6) and two Black Washers (8 and 9).
  • Page 21 Assembly Instructions S/T/U/V 41. Position the Glass Tops (A and B) onto the assembled unit so that the threaded sockets underneath the metal plates overlap the drilled holes simultaneously. Insert four 32 mm Bolts (7) with the Black Washers (8 and 9) through the drilled holes on both Top Panels (C and H) and insert eleven 35 mm Zinc Bolts (10) with the Zinc Washers (12 and 13) through the Upper Stretchers (S, T, U and V) and securely screw into place.

  • Page 22: Care And Maintenance

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
