VAS BBCXL505GB Assembly Instructions Manual

50” 3-in-1 console
Hide thumbs Also See for BBCXL505GB:

Advertisement

Quick Links

Download this manual
50" 3-in-1 Console
Option 1: Console with Swinging Floater
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if you are missing parts, do not return this item
to the Retailer Store. Please call our toll free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-866-942-5362 8:30 a.m. - 4:30 p.m. PST, Monday - Friday
ONLINE: www.whalenfurniture.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
VAS Furniture Mfg. Inc.
Video Instruction Guides
Go to http://whalen.showuhow.com to view step-by-step instructional
videos for assembling and installing your product. Enter the following
product number on the ShowUhow homepage.
BBCXL505GB
EMAIL: parts@whalenfurniture.com
Factory No. 56-12089
MODEL # BBCXL505GB
LOT No.:
DATE OF PURCHASE: / /
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BBCXL505GB and is the answer not in the manual?

Questions and answers

Related Manuals for VAS BBCXL505GB

Summary of Contents for VAS BBCXL505GB

  • Page 1 MODEL # BBCXL505GB LOT No.: DATE OF PURCHASE: / / 50” 3-in-1 Console Option 1: Console with Swinging Floater ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if you are missing parts, do not return this item to the Retailer Store.

  • Page 2: Quality Guarantee

    Model # BBCXL505GB QUALITY GUARANTEE We are confident that you will be delighted with your VAS Furniture purchase. Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase.
  • Page 3 Model # BBCXL505GB Parts List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A-Top Shelf Frame (1) B- Middle Shelf Frame (1) C- Bottom Shelf Frame (1) D- Long Spine (1)
  • Page 4 Model # BBCXL505GB Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. (2) - 3/4” Bolt (24+1 extra) (3) - 1 1/4” Bolt (6+1 extra) (1)- Suction Cup (16+1 extra)
  • Page 5 Model # BBCXL505GB Assembly Instructions Note: Please do not fully tighten all bolts until you finish assembling all parts, then go back and fully tighten all bolts, this will make it easier during assembly of unit. 1. Unpack the unit and confirm that you have all the hardware and required parts listed.
  • Page 6 Model # BBCXL505GB Assembly Instructions 4. Stand the unit upright. 5. Pick up Left Leg (E) and attach to the Middle & Bottom Shelf Frame (B & C) by inserting the 1 1/4” Bolts (3) with Washers (5 & 6) from inside the shelf frame through the pre-drilled holes on side rail into the threaded inserts on Leg.
  • Page 7 Model # BBCXL505GB Assembly Instructions 8. Go back and tighten all bolts with Allen Wrench provided. 9. In case of uneven floor, Floor Levelers are provided at the bottom of both Legs (E & F). Simply tilt the unit back and raise or lower floor leveler by hand to correct tilting as shown in detail #3.
  • Page 8 Model # BBCXL505GB Assembly Instructions attach Swiveling Bracket (J) to the top of Spine (D) using six 3/4” Bolts (2) with Align and Washers (5 & 6). Make sure the swivel bolt head is up. See detail # Note: The Spine can provide four height options for your TV set. Refer to your TV size, adjust the Swiveling Bracket at your desired height to offer optimum viewing.
  • Page 9 Model # BBCXL505GB Assembly Instructions 11. Hold the flat side of XYZ Mounting Frame (K) onto the Swiveling Bracket (J) ensuring the hook on the side of Mounting Frame is bottom. Align and attach by threading four 3/4” Bolts (2) with Flat Washers (6) through the metal plate on XYZ Mounting Frame and the Swiveling Bracket, at the other side of Swiveling Bracket place the other Flat Washers (6) and Lock Washers (5), and then secure with Nuts (4).
  • Page 10 Model # BBCXL505GB Mounting Monitor Bracket to a television with a flat back Note: For televisions with a curved back or recessed back proceed directly to step #15. 12. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV.
  • Page 11 Model # BBCXL505GB Mounting Monitor Bracket to a television with a curved / recess back 15. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV. If you encounter any resistance, stop immediately. If you are unable to find the correct bolt consult a local hardware store.
  • Page 12 Model # BBCXL505GB Assembly Instructions MAKE SURE ALL BOLTS ARE TIGHT AND SPINE IS AT A 90 DEGREE ANGLE PRIOR TO INSTALLATION OF TV. 18. Once the Monitor Brackets (L) are attached onto the back of television, ask for assistance to lift the television up to the XYZ Mounting Frame (K).
  • Page 13 Model # BBCXL505GB Assembly Instructions 20. Put the Suction Cups (1) firmly into top holes of the Middle Shelf Frame (B) & Bottom Shelf Frame (C) as shown in detail #9. 21. Screw the Glass Raisers (7) onto the top holes of Top Shelf Frame (A), make sure they go all the way in.

  • Page 14: Tipping Restraint Hardware

    Model # BBCXL505GB TIPPING RESTRAINT HARDWARE Note: We have included one Tipping Restraint Hardware bag for this Unit. When properly installed, this restraint can provide protection against the unexpected tipping of the Unit due to small tremors, bumps or climbing. We strongly recommend mounting this hardware to a wall stud and your unit when installing.
