Installation
C
D
E
F
12
A
B
G
H
K
J
Figure 3-5. Typical SACM Connections
1
2
1
2
1
2
1
2
T1
N1
N2
T1
0
N1
N2
194
0 DC GROUND
194 +12 VDC
23
T1
23 TRANSFER
®
®
N2 N1 T1
006244
Automatic Transfer Switch Owner's Manual
A
Thermostat 1
B
Air Conditioner 1
C
Thermostat 2
D
Air Conditioner 2
E
Thermostat 3
F
Air Conditioner 3
G
Thermostat 4
H
Air Conditioner 4
T1 (fused)
Battery Charge
N1 (fused)
Utility Sense
N2 (fused)
Utility Sense
0 DC
Ground
194
+ 12 VDC
23
Transfer Control
J
240 VAC, 6.3A
Fuses
K
Spare Fuse
