PC51O2-433NA v1.0 Installation Manual
If you are intending to use DLS-3 software with this product, a new DLS-3 driver must be
downloaded from the DSC web site at http://www.dscsec.com/dls3drivers.htm. Install
this driver on your computer in the same directory as your DLS-3 software.
Section 1: Introduction
Section 1: Introduction
Section 1: Introduction
Section 1: Introduction
Section 1: Introduction
This manual describes how to install, program and maintain the PC5102-433. Before you
install the PC5102-433 module, you should complete the following steps in your system
installation:
1. Plan the installation and wiring of the security system (see your system Installation Manual ).
2. Install the control panel, and install and enroll at least one keypad to use for programming.
Program the PC5102-433 from a system keypad or using DLS-3 v1.3 with the PC5102-433
v1.0 Driver Pack. Read your system Installation Manual for more information.
1.1
How to Use this Manual
Read this manual before you begin installing the PC5102-433. To install and set up the
PC5102-433 and wireless keys, follow these steps. Refer to the sections listed below.
1. Temporarily mount and wire the PC5102-433 module (see Section 2 ).
2. Enroll and program wireless keys (see Section 3 ).
3. Complete PGM and other programming on the system (see Section 4 ).
4. Test the placement of all the wireless keys (see Section 5).
5. Permanently mount the PC5102-433 receiver (see Section 5).
For additional information on trouble conditions and battery replacement, see Section 6.
For help with troubleshooting, see Section 7.
1.2
Specifications and Features
• Current Draw: 50mA (standby) 200mA maximum (both outputs active)
• Frequency: 433 MHz
• Receiver can receive signals from up to 8 wireless keys
• Antenna - internal. Installation not required
• Location
- can be wired up to 750 ft/230m. from the main panel with 22 gauge wire
- connects to Keybus
- for longer wire runs, thicker gauge wire must be used
• Compatibility: The PC5102-433 v1.X can be connected to the following panels:
PC501X, P832/DL, PC5020, P-8+, PC1555, P-6B, PC1555MX, P-6BMX, PC580, P-48
1.3
Compatible Wireless Keys
Please refer to the instruction sheets of the following keys for more information.
The PC5102-433 v1.X can receive signals from the following keys:
• WLS909-433 Wireless Key
• PWLS909-433 Wireless Key
This manual contains information on limitations regarding
product use and function and information on the limitations as
W A R N I N G
to liability of the manufacturer.
firealarmresources.com
• WLS919-433 Wireless Key
• PWLS919-433 Wireless Key
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DSC PC5102-433
Summary of Contents for DSC PC5102-433
-
Page 1: Section 1: Introduction
Driver Pack. Read your system Installation Manual for more information. How to Use this Manual Read this manual before you begin installing the PC5102-433. To install and set up the PC5102-433 and wireless keys, follow these steps. Refer to the sections listed below. -
Page 2: Section 2: Pc5102-433 Set Up & Wiring
NOTE: Make sure that electrical wires will not run over the antenna of the module when it is mounted. When mounting the PC5102-433 in a basement, place the module as high and as close to the underside of the first floor as possible. The range of the module will be reduced if the unit is mounted below ground level. -
Page 3: Section 3: Enrolling Wireless Keys
Doing this will also activate an output on the PC5102-433 for 5 seconds (please refer to the control panel manual for a listing of available output types and their functions). PGM 1 and/or PGM 2 on the PC5102-433 can be set up to open a garage door (please refer to Section 4.1). - Page 4 Enroll & Program Wireless Keys For wireless keys to work on the system, you need to enroll them and then program the function buttons, if the default values are not the functions desired. Wireless keys are not assigned to zones and require no zone programming. You can enroll up to 8 wireless keys on the system. Enroll Wireless keys 1.
-
Page 5: Section 4: Other Programming
Section 4: Other Programming Section 4: Other Programming PC5102 PGM Outputs The PC5102-433 has two on-board Form C relay PGM outputs. Each of these can be individually programmed to: 1. Follow main panel PGM outputs 1 to 14. NOTE: Please refer to your System Installation Manual for available PGM outputs. -
Page 6: Section 5: Testing & Mounting
The system will generate a General System Supervisory trouble if the module is removed from the Keybus. If you need to remove the PC5102-433 module from an existing system, you will have to disable supervision of the PC5102-433. NOTE NOTE... -
Page 7: Section 6: Additional Notes
Mount the PC5102-433 When you have tested reception of the PC5102-433 with all the wireless devices (see section 5.1) and you have a good mounting location, mount the PC5102: 1. Pull the Keybus wires through the hole at the bottom of the back part of the cabinet. -
Page 8: Section 7: Troubleshooting
• Verify that the device is in range of the PC5102. Try testing the device in the same room as the receiver. • Confirm that the PC5102-433 is properly connected to the Keybus (see section 2 for PC5102-433 setup and wiring instructions). - Page 9 Wireless Key Options l l u [✱ i t c [✱ [✱ [✱ [✱ [✱ [✱ a i l [✱ [✱ t i x Wireless Key Options Partition 1 Wireless Key Options [61] Function Key 1 Function Key 3 l _ ___ l _ ___ l l _ ___ l _ ___ l Function Key 2 Function Key 4...
- Page 10 Partition 8 Wireless Key Options [68] Function Key 1 Function Key 3 l _ ___ l _ ___ l l _ ___ l _ ___ l Function Key 2 Function Key 4 l _ ___ l _ ___ l l _ ___ l _ ___ l [91] Wireless Keys (1-8) Partition Assignments Default = 01 Wireless Key 05...
- Page 11 WARNING Please Read Carefully Note to Installers reach the smoke detectors, such as when the fire is in a chimney, walls or This warning contains vital information. As the only individual in contact with roofs, or on the other side of closed doors. Smoke detectors may not detect system users, it is your responsibility to bring each item in this warning to the smoke from fires on another level of the residence or building.
- Page 12 Ltd.); to perform as expected. • defects caused by failure to provide a suitable in- ©2001 Digital Security Controls Ltd. Toronto, Canada • 1-800-387-3630 • www.dsc.com Printed in Canada 29034480 R002 firealarmresources.com...
