• W A R N I N G •
This manual contains information on limitations regarding
product use and function and information on the limitations as
to liability of the manufacturer.
Installation
Manual
PC51O2-433NA
version 1.O
If you are intending to use DLS-3 software with this product, a new DLS-3 driver must
be downloaded from the DSC web site at http://www.dscsec.com/dls3drivers.htm.
Install this driver on your computer in the same directory as your DLS-3 software.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC51O2-433NA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DSC PC51O2-433NA

Summary of Contents for DSC PC51O2-433NA

  • Page 1 1.O If you are intending to use DLS-3 software with this product, a new DLS-3 driver must be downloaded from the DSC web site at http://www.dscsec.com/dls3drivers.htm. Install this driver on your computer in the same directory as your DLS-3 software.

  • Page 2: Warning Please Read Carefully

    WARNING Please Read Carefully Note to Installers This warning contains vital information. As the only individual in contact Smoke detectors may not detect smoke from fires on another level with system users, it is your responsibility to bring each item in this warn- of the residence or building.
  • Page 3 Thank you for purchasing the PC5102-433 Wireless Receiver. This product will allow you to connect up to 8 wireless keys to the PC580, P-48, PC1555(MX), P-6B(MX), P-48, P832/DL, P-8+ and the PowerSeries control panels. The PC5102-433 operates on the 433 MHz frequency. It provides on-board PGMs and features a 6-digit serial number for all wireless devices.

  • Page 4: Table Of Contents

    Table of Contents Introduction How to Use this Manual ................ 1 Specifications and Features ..............1 Compatible Wireless Keys ..............2 Batteries ....................2 PC5102-433 Set Up & Wiring Choose a Mounting Location for the PC5102-433 ........ 3 Terminal Descriptions ................3 Connecting the PC5102-433 Receiver ..........

  • Page 5: Introduction

    Introduction This manual describes how to install, program and maintain the PC5102-433. Before you install the PC5102-433 module, you should complete the following steps in your system installation: 1. Plan the installation and wiring of the security system (see your system Installation Manual ).

  • Page 6: Compatible Wireless Keys

    1.3 Compatible Wireless Keys Please refer to the instruction sheets of the following keys for more information. The PC5102-433 v1.X can receive signals from the following keys: • WLS909-433 Wireless Key • WLS919-433 Wireless Key • PWLS909-433 Wireless Key • PWLS919-433 Wireless Key 1.4 Batteries The PWLS909-433/WLS909-433 use three A-76 batteries and the PWLS919-433/ WLS919-433 use two CR2032 Lithium batteries.

  • Page 7: Pc5102-433 Set Up & Wiring

    PC5102-433 Set Up & Wiring This section describes how to set up and wire the PC5102-433 module. 2.1 Choose a Mounting Location for the PC5102-433 NOTE NOTE NOTE NOTE NOTE: Mount the PC5102-433 receiver and wireless keys after you have done placement tests with the wireless keys (see sections 5.1 and 5.2).

  • Page 8: Connecting The Pc5102-433 Receiver

    & 2.3 Connecting the PC5102-433 Receiver CAUTION: Remove all power from the system while connecting modules to the Keybus . Connect the PC5102-433 to the four-wire Keybus of the control panel according to the following diagram. Control Panel RED BLK YEL GRN KEYBUS TO PC5102 After you have completed the wiring, reconnect the power to the security system.

  • Page 9: Connecting An X-10 Powerflash Module To The Pc5102-433

    & 2.6 Connecting an X-10 Powerflash Module to the PC5102-433 When connecting an X-10 Powerflash module to the PC5102-433, different lights within or outside the home can be controlled, such as table lamps, or porch and driveway lights that illuminate the entry / exit paths. This can be done by setting up the system and wireless key in one of several ways: •...

  • Page 10: Enrolling Wireless Keys

    Enrolling Wireless Keys This section describes how to enroll wireless keys. For more information on these keys, read the instruction sheet included with each key. 3.1 A Note about Electronic Serial Numbers An electronic serial number (ESN) is printed on the back of each wireless key. ESNs are used to enroll the wireless keys with the PC5102-433 receiver.

  • Page 11: Identified Wireless Keys

    For systems using partitions (PC5020/P-8+/PC501X/P832/P832DL only): All wire- less keys assigned to Partition 1 will have the four functions programmed in section [61]. All wireless keys assigned to Partition 2-8 will have the four functions programmed in section [62-68]. For example, if function button 1 in Section [61] is programmed for Stay arming, then pressing the first button on wireless keys assigned to Partition 1 will Stay arm Partition 1.
  • Page 12 Command Output Activation NOTE NOTE NOTE NOTE NOTE: The Identified Wireless Key Command Output Activation feature is only avail- able with the PC5020, P-8+, PC501X, P832/DL, PC1555(MX), P-6B(MX), PC580 v2.0 and higher and P-48 v2.0 and higher. To enable command output activation by wireless keys, ensure that: •...

  • Page 13: Other Programming

    Other Programming 4.1 PC5102 PGM Outputs The PC5102-433 has two on-board Form C relay PGM outputs. Each of these can be individually programmed to: 1. Follow main panel PGM outputs 1 to 14. NOTE: Please refer to your System Installation Manual for available PGM outputs. NOTE: If the PC5102-433 is connected to the PC580/PC1555/P-48/P-6B (all versions), PC5010 v1.x, P832 v1.x or the WSS5010 1.0, 2.1, the PC5102 PGM outputs cannot be programmed to follow main panel PGM outputs 1 or 2.

  • Page 14: Pc5102-433 Software Default

    If the PC5102-433 module does not show on the keypad, one of the following conditions may be present: • the module is not connected properly to the Keybus • there is a problem with the Keybus wiring run • the module does not have enough power •...

  • Page 15: Testing & Mounting

    Testing & Mounting 5.1 Test the Reception of Wireless Keys It is very important to test each wireless key. Following these steps will test the signal strength between the PC5102-433 and the wireless key. Testing Individual Wireless Keys To ensure that the PC5102-433 receiver is receiving transmissions from these devices, use the function keys on the (P)WLS909-433/(P)WLS919-433 at several different locations in the installation.

  • Page 16: Additional Notes

    Additional Notes 6.1 Trouble Conditions The control panel always watches for possible trouble conditions. If a trouble condition occurs, the keypad “Trouble” light will turn on and the keypad will beep. Press [✱][2] to display the trouble conditions. The following trouble conditions apply to the PC5102-433 and/or any enrolled wireless keys.

  • Page 17: Troubleshooting

    Troubleshooting 1. When I enter Sections [41] - [48] to add a wireless key, the keypad sounds a long beep. You cannot enter ESNs unless a PC5102-433 wireless receiver is connected to the Keybus. See section 2 for instructions on setting up and wiring the PC5102-433 module.

  • Page 18: Programming Worksheets

    Programming Worksheets [804] 5102-433 Wireless Expansion Programming • 6-digit entry is required. See Section 3.1 “A note on Electronic Serial Numbers” for details on programming 6-digit serial numbers. Wireless Key Serial Numbers Default = 000000 [41] Key 01 [45] Key 05 l _____ l _____ l _____ l _____ l _____ l _____ l l _____ l _____ l _____ l _____ l _____ l _____ l [42] Key 02...

  • Page 19: Wireless Key Options

    Wireless Key Options Partition 1 Wireless Key Options [61] Function Key 1 Function Key 3 l _ ___ l _ ___ l l _ ___ l _ ___ l Function Key 2 Function Key 4 l _ ___ l _ ___ l l _ ___ l _ ___ l Partition 2 Wireless Key Options [62] Function Key 1...
  • Page 20 PC5102 Output Options Entry Description Null (No Operation) Main Panel PGM1 Main Panel PGM2 PC5208 PGM3 PC5208 PGM4 PC5208 PGM5 PC5208 PGM6 PC5208 PGM7 PC5208 PGM8 PC5208 PGM9 PC5208 PGM10 PC5204 PGM11 PC5204 PGM12 PC5204 PGM13 PC5204 PGM14 PC5102 PGM Pulse (local) PC5102 PGM Toggle (local) [92] PC5102 PGM1 Output Option...

  • Page 21: Index

    Index Index Index Index Index individual placement serial number 6 wireless key 6 test 11 slot number antenna 1 interference 3 wireless key 6 supervision DEOL 10 batteries Keybus 4 device 10 disable 9 replacing 12 module 9 type 2 window 10 buttons location...

  • Page 22: Limited Warranty

    LIMITED WARRANTY Digital Security Controls Ltd. warrants the original purchaser Digital Security Controls Ltd.’s liability for failure to repair that for a period of twelve months from the date of purchase, the product under this warranty after a reasonable number the product shall be free of defects in materials and of attempts will be limited to a replacement of the product, workmanship under normal use.

  • Page 23: Fcc Compliance Statement

    FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment. This equipment generates and uses radio frequency energy and if not installed and used properly, in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception.
  • Page 24 ©2001 Digital Security Controls Ltd. Toronto, Canada 1-888-888-7838 • www.dsc.com Printed in Canada 29034480 R001...
