HP ProCurve Switch 2610 Series

Features and benefits

Industry-leading warranty
Connectivity
• IEEE 802.3af Power over Ethernet: provides up to 15.4 W per
port to IEEE 802.3af compliant PoE powered devices such as IP
phones, wireless access points, and security cameras
• Pre-standard PoE support: detects and provides power to
pre-standard PoE devices; see list of supported devices in the
product FAQ at www.ProCurve.com
• Gigabit Uplink Connectivity: two 10/100/1000BASE-T ports
and two mini-GBIC ports for connectivity such as Gigabit (SX, LX,
LH, 1000BaseT) and 100Base-FX
• ProCurve Auto-MDIX: automatically adjusts for straight-through
or crossover cables on all 10/100 ports
• Jumbo packet support: supports up to 9,216 byte frame size to
improve performance of large data transfers

Resiliency and high availability

• IEEE 802.3ad Link Aggregation Protocol (LACP) and
ProCurve trunking: support up to 24 trunks, each with up to 8
links (ports) per trunk
• IEEE 802.1s Multiple Spanning Tree: provides high link
availability in multiple VLAN environments by allowing multiple
spanning trees; provides legacy support for IEEE 802.1d and
IEEE 802.1w
• Optional redundant power supply: provides uninterrupted
power (provided by HP ProCurve 600 RPS/EPS)
Manageability
• RMON, XRMON, and sFlow: provide advanced monitoring and
reporting capabilities for statistics, history, alarms, and events
• Uni-Directional Link Detection (UDLD): monitors a link
between two switches and blocks the ports on both ends of the
link if the link goes down at any point between the two devices
♦ For as long as you own the product, with next-business-day advance replacement (available in most countries). The following hardware products and their related series modules have a one-year
hardware warranty with extensions available: HP ProCurve Routing Switch 9300m series, HP ProCurve Switch 8100fl series, HP ProCurve Network Access Controller 800, and HP ProCurve DCM
Controller. The following hardware mobility products have a one-year hardware warranty with extensions available: HP ProCurve M111 Client Bridge, HP ProCurve MSM3xx-R Access Points, HP
ProCurve MSM7xx Mobility and Access Controllers, HP ProCurve RF Manager IDS/IPS Systems, HP ProCurve MSM Power Supplies, HP ProCurve 1 Port Power Injector, and HP ProCurve CNMS
Appliances. Disk drives in the HP ProCurve ONE Services zl modules have a five year hardware warranty. Standalone software, upgrades, or licenses may have a different warranty duration. For details,
refer to the ProCurve Software License, Warranty, and Support booklet at http://www.procurve.com/warranty.
• Command authorization: leverages RADIUS to link a custom
list of CLI commands to individual network administrator's login;
also provides an audit trail
• Multiple configuration files: allow multiple configuration files to
be stored to flash image
• Dual flash images: provides independent primary and
secondary operating system files for backup while upgrading
• Stacking capability: single IP address management for a virtual
stack of up to 16 switches, including the HP ProCurve Switch
2500 Series, 2510 Series, 2600 Series, 2610 Series, 2810 Series,
2900 Series, 3400cl Series, 3500l Series, 4200vl Series, 6108,
6200yl-24G-mGBIC, and 6400cl Series
• Friendly port names: allow assignment of descriptive names to
ports
• Find-Fix-and-Inform: finds and fixes common network problems
automatically, then informs administrator
• Software updates: free downloads from the Web
• Troubleshooting: ingress/egress port monitoring enables
network problem-solving

Layer 2 switching

• VLAN support and tagging: supports the IEEE 802.1Q (4,094
VLAN IDs) and 256 VLANs simultaneously
• GARP VLAN Registration Protocol: allows automatic learning
and dynamic assignment of VLANs

Layer 3 routing

• Basic IP routing: enables automatic routing to the connected
VLANs and up to 16 static routes--including one default route--in
IP networks
Security
• Multiple user authentication methods:
- IEEE 802.1X: industry-standard method of user authentication
using an IEEE 802.1X supplicant on the client in conjunction with
a RADIUS server
- Web-based authentication: similar to IEEE 802.1X, provides a
browser-based environment to authenticate clients that do not
support the IEEE 802.1X supplicant
- MAC-based authentication: client is authenticated with the
RADIUS server based on the client's MAC address
