  • Page 1 RM50000 Series ENGLISH ........... FRANÇAIS ........ESPAÑOL ........Broan-NuTone LLC. 926 West State Street, Hartford, WI 53027 NuTone, Inc., 4820 Red Bank Road, Cincinnati, OH 45227 Broan-NuTone Canada, Inc.1140 Tristar Drive, Mississauga, Ontario, L5T 1H9...

  • Page 2: To Reduce The Risk Of Fire, Electric Shock, Or Injury To Persons, Observe The Following

    READ AND SAVE THESE INSTRUCTIONS INTENDED FOR DOMESTIC COOKING ONLY WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: 1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address or telephone number listed in the warranty.
  • Page 3 CAUTION 1. To reduce risk of fire and to properly exhaust air, be sure to duct air outside. Do not vent exhaust air into spaces within walls or ceilings or into attics, crawl spaces, or garages. 2. Take care when using cleaning agents or detergents. 3.

  • Page 4: Prepare The Hood

    PREPARE THE HOOD 8 - Mounting Screws (4.8 x 38mm Pan Head) 4 - Mounting Screws Unpack hood and check contents. (3.9 x 9.5mm Pan Head) You should receive: 8 - Drywall Anchors 1 - Hood 1 - Plenum 1 - Decorative Flue Assembly 4 - Mounting Screws 1 - Adapter (3.4 x 15mm Flat Head)

  • Page 5: Install The Ductwork

    INSTALL THE DUCTWORK (DUCTED HOODS ONLY) ROOF CAP ROUND NOTE: To reduce the risk of fire, use only DUCT metal ductwork. 1. Decide where the ductwork will run between the hood and the outside. 2. A straight, short duct run will allow the hood DECORATIVE WALL FLUE...

  • Page 6: Install Mounting Bracket

    INSTALL MOUNTING BRACKET FRAMING BEHIND DRYWALL 1. Construct wood wall framing that is flush with interior surface of wall studs. Make sure: a) the framing is centered over installation location. b) the height of the framing will allow the mounting bracket to be secured to the framing within the dimensions shown.
  • Page 7 2. Attach an adequate length of 6” round steel UPPER UPPER ducting to the range hood duct connector. FLUE FLUE Fig.6 VENTS 3. Duct tape all joints to make them secure EXPOSED and air tight. LOWER FLUE UPPER FLUE 4. Carefully place the lower decorative flue VENTS into the recessed area of the range hood CONCEALED...

  • Page 8: Install The Hood

    PREPARE THE HOOD PLENUM NON - DUCTED CONFIGURATION, cont’d. 8. Carefully place the lower decorative flue into the recessed area of the range hood top. Fig.7 9. Carefully slide the upper decorative flue down inside the lower flue. Note: air vents must be up. Fig.7 10.Secure the recirculation plenum to the 4 FLAT HEAD...

  • Page 9: Non-Ducted Recirculation Filters

    NON-DUCTED RECIRCULATION FILTERS INSTALLATION 1. Non-ducted recirculation filters (B03300487) is included. 2. Position the filters over the blower. 3. Rotate to lock filters in place. NON-DUCTED RECIRCULATION FILTERS fig.12 MAINTENANCE Proper maintenance of the Range Hood will assure proper performance of the unit. Grease Filter The grease filter should be cleaned frequently.

  • Page 10: Operation

    OPERATION BLOWER LIGHT SWITCH SWITCH PILOT Controls LAMP The hood is operated using the slide controls under the bottom of the hood. The light switch turns the lamps on and off. 0 1 2 3 4 The blower switch: makes it possible to select the motor operating speed.

  • Page 11: Warranty
