NuTone RM604201 Specification Sheet

RM60000 SERIES
PRO-STYLE

RANGE HOOD

(Original Rangemaster)
Provides high ventilation and durable construction
to meet the needs of professional-quality residential
cooktops.
A complete installation requires several optional compo-
nents. Refer to page 2 when planning your installation
FEATURES
HOOD:
•
Widths - 30" to 72" in 6" increments
•
Finishes - Stainless Steel*, White**, and Black** appli-
ance colors
•
Appliance colors in 54", 60", 66" & 72" widths are Spe-
cial Orders
•
Grease filters are dishwasher safe
•
Dual food warming lamps (BR40 Size, 250W, Infrared
- purchase separately)
•
Three-level cooktop lighting (Uses three, 50W,
PAR 20 halogen lamps - purchase separately)
•
Solid-State, infinite speed blower control with speed
memory
•
Exclusive, Broan Heat Sentry™ turns blower ON to
HIGH speed when excess heat is detected
BAFFLE FILTER KIT:
RBF Series (Optional)
•
Available for all hood widths
BACKSPLASH:
RMP Series (Optional)
•
Widths - 30" to 72" in 6" increments
•
Stainless Steel* construction - protects back wall and
wipes clean easily
•
Two, removable, dual-position food warming / condi-
ment storage shelves
SOFFIT CHIMNEY:
RMN Series (Optional)
•
Widths - 30" to 72" in 6" increments
•
Finishes - Stainless Steel*, White**, and Black** appli-
ance colors
•
Appliance colors in 54", 60", 66" and 72" widths are
Special Orders
•
Recommended for use when installation location has no
soffit
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
NuTone, Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687)
Broan-NuTone Canada, Inc., 1140 Tristar Drive, Mississauga, Ontario L5T 1H9 (1-888-882-7626)
REFERENCE QTY.
RMP Series
Backsplash
(Optional)
REMARKS
SPECIFICATION SHEET
* 22 gauge, type 430
stainless steel
** 22 gauge, painted
galvanneal
Project
Location
Architect
Engineer
Contractor
Submitted By
70D
Intended for
domestic
cooking only.
RM60000 Series
Hood
RMN Series Sof-
fit Chimney
(Optional)
Date
99043133D
