1

MP110 GENERAL INFORMATION

1.1 Physical Interfaces

1
Ethernet Port
2
USB Port
3
System Power /Running LED
4
Digital Input Status Information
5
Digital Output Status Information
6
Protocol Data Transfer LED
7
Device Power (V+/V-) Connection
6
Figure 1 Connector and Physical Interfaces
8
Antenna Connection
9
Digital Input Connections
10
SIM Card Slot
11
Analog Input Connections
12
Digital Output Connections
13
Expansion Connector
14
RS485 Connections
MP110 SERIES – HARDWARE MANUAL
