ENGINEERING DATA

MODEL
SPECIFICATIONS
Rated Capacity a - (scfm)
Inlet /Outlet Connections - (inches)
Dimensions
Height - (inches)
Length - (inches)
Width - (inches)
Power Supply - (V/Ph/Hz)
Refrigerant Compressor Rating - (hp)
Input Power - (kW)
Refrigerant Type b
a Rating conditions are 100°F inlet temperature, 100 psig inlet pressure, 100% inlet relative humidity, 100°F ambient temperature @ 60Hz. Per CAGI ADF-100.
b Refer to dryer data plate for refrigerant charge.
MODEL
MINIMUM - MAXIMUM OPERATING CONDITIONS
Min.-Max. Inlet Air Pressure (compressed air at inlet to dryer)
Min.-Max. Inlet Air Temperature (compressed air at inlet to dryer)
Min.-Max. Ambient Temperature
NOTE: Continuous operation in the above maximum and minimum operation conditions is not allowable.
HG25 HG35
25 35
3/4 3/4
22.2 22.2
15.5 15.5
14.5 14.5
115/1/60 115/1/60
1/4 1/4
0.47 0.47
R-134a R-134a
HG25, HG35, HG50
30 - 250 psig
40°F - 120°F
40°F - 110°F
HG50
50
3/4
22.2
19.7
19.7
115/1/60
1/3
0.63
R-134a
7
