Android Box
ENJOY TV QUAD CORE BOX
APC395X
User's Guide
Thank you for purchasing this Geniatech product.
.Before using it, be sure to read the precautions contained in this User's Guide.
.Keep the User's Guide in a safe place for future reference.
.For the most up-to-date information about this product, visit official website at
http://www.geniatech.com
1

Advertisement

Table of Contents
loading

Related Manuals for Geniatech APC395X

Summary of Contents for Geniatech APC395X

  • Page 1 ENJOY TV QUAD CORE BOX APC395X User’s Guide Thank you for purchasing this Geniatech product. .Before using it, be sure to read the precautions contained in this User’s Guide. .Keep the User’s Guide in a safe place for future reference.

  • Page 2: Table Of Contents

    Contents 1. Safety Information, P3-4 1.1 Warning, P3 1.2 Precautions, P3-4 1.3 Handling Cautions, P4 2. Introduction, P5-8 2.1 Package Contents, P5 2.2 Product Features, P5 2.3 Panel Introduction, P6 2.4 Remote Controller, P7 2.5 Setup Connection, P7 2.6 Display when Power Up, P8 3.

  • Page 3: Safety Information

    1. Safety Information Read and understand all instructions before using this product. If damage is caused by failure to follow the instructions, the warranty does not apply. 1.1 Warning To reduce the risk of electric shock, DO NOT remove the cover (or back). DO NOT attempt to repair the product, this could lead to the risk of injury, damage to the product .

  • Page 4: Handling Cautions, P4

    convenience receptacles, and the point where it exits the apparatus. 1.2.10 Only use attachments/accessories specified by the manufacturer. 1.2.11 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used , use caution when moving the cart/apparatus combination to avoid injury from tip-over.

  • Page 5: Introduction

    2. Introduction 2.1 Package Contents Enjoy TV Quad Core Box - APC395X white User’s Guide HDMI Cable IR Remote Controller (IR RC) Optional Remote Controller 2.4G wireless Remote Controller USB wire/wireless Mouse & Keyboard Power Adapter, Input: AC100 ~ 240V, 50/60Hz, Output: 5V, 2A 2.2 Product Features...

  • Page 6: Panel Introduction, P6

    2.3 Panel Introduction...

  • Page 7: Remote Controller, P7

    ⑦ Downwards ⑰ Page Down ⑧ OK ⑨ Return Note: Button Battery 2025 3V insert with correct polarity (+/-). 2.5 Setup Connection Place APC395X on a flat platform near the TV, and make sure nothing block the remote control signal.

  • Page 8: Display When Power Up, P8

    2.6 Display when Power Up 2.6.1 After power up, the TV will first show Geniatech logo,starting with Enjoy TV boot animation. When finished, it will go to Home screen. 2.6.2 Home Screen display.

  • Page 9: Settings

    3. Settings Using Navigation (4 directions), OK, EXIT, and Menu keys of Remote Controller to select the options, the option selected will be highlighted and confirmed by pressing OK key. Same operation for text input if needed. Select icon then press OK key to settings interface Or Select icon to settings interface.
  • Page 10 Or fail to connect and need reset password. 3.1.3 Once build up the connection with a certain WiFi network successfully, APC395X will connect this WiFi network automatically when restart. Note: If factory reset, the password of WiFi network have to be reset. 3.2 Bluetooth...

  • Page 11: More

    3.3 Ethernet Connect Box and Router by RJ45 network cable. Press “ ON” in Ethernet setting, it will connect to network automatically. 3.4 More...

  • Page 12: Sound And Notification, P12-13

    3.4.1 VPN Edit VPN profile 3.4.2 Portable hot spot 3.4.2.1 Enable Portable hot spot 3.4.2.2 Set up WiFi hot spot WiFi and hot spot connection can not be applied at same time. Disconnect WiFi and connect Ethernet while using hot spot function. 3.5 Sound and notification 3.5.1 Sound Increase or decrease sound volumes...
  • Page 13 3.5.2 Touch Sounds Choose Other sounds,you can set touch sound , if enable Touch sound, sound will be heard while move remote controller. 3.6 Display...
  • Page 14 3.6.1 Wallpaper You can choose different wallpaper from gallery, live wallpaper and wallpaper. 3.6.2 Sleep...
  • Page 15 3.6.3 Daydream 3.6.4 Font size Change the font size of OSD...

  • Page 16: Storage&Usb, P16

    3.7 Storage&USB Shows the storage used of the OS and SD card. 3.8 Apps List all apps installed. You can choose an application and force to shut down the app, uninstall the app, clear user data, move to SD card and clear cache data.
  • Page 17 3.9 Memory 3.10 Location...

  • Page 18: Language & Input, P18

    3.11 Security 3.12 Language & input Change OSD language and input method. The default input method is android standard keyboard. If you are using our IR remote control, enter into “Default” option and switch to remote controller input method.
  • Page 19 3.13 Reset Factory data reset This will erase all data from your mbox’s internal storage,including: ·Your Google account ·System and app data and settings ·Downloaded apps ·Music\Photos ·Other user data You can reset all the settings and apps to factory default. Note: Once you choose to reset to factory default, all data/apps will be deleted.
  • Page 20 3.15 Google...

  • Page 21: Date Time, P21

    3.16 Date time 3.17 About MediaBox...

  • Page 22: Apps Install & Uninstall

    4. Apps Install & Uninstall On APC395X, you can install apps from Android Market over the Internet or other sources, such as other online sources, the internal storage and the USB storage device and SD card that you have mounted onto APC395X.

  • Page 23: Firmware Update

    5. Firmware Update You can download newest firmware from Geniatech Official website: www.geniatech.com...

  • Page 24: Trouble Shooting/Faq

    6. Trouble Shooting/FAQ 6.1 No Picture Refer to the TV user manual for how to select the correct video input channel. 6.2 USB Content cannot be read . The format of USB storage device is not supported . The supported memory size is 32G maximum. .

  • Page 25: Repairs

    We will provide you with the amount of the administration fee before we make a home visit or begin any work on your player. We recommend you read this manual throughly, search for a solution on line at www.geniatech.com, or contact Geniatech Customer Care before seeking to repair your player.

  • Page 26: Specification

    8. Specification Quad Core ARM Cortex-A53 CPU up to @ 2.0GHz Mali 450 GPU @ 750MHz+(DVFS) 2G DDR3(1G optional) 8G EMMC Android 6.0 OS Optional DOLBY USB2.0 x2 HDMI V2.0 DC Input 5.0V-2A SD Slot Max: 32G Video Output HDMI/CVBS Audio Output HDMI/RCA IR receiver...

  • Page 27: Trademark Notice

    9. Trademark Notice The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in United States and other countries.
