Android Box
ANDRIOD TV QUAD CORE BOX
ATV598MAX
User's Guide
Thank you for purchasing this Geniatech product.
.Before using it, be sure to read the precautions contained in this User's Guide.
.Keep the User's Guide in a safe place for future reference.
.For the most up-to-date information about this product, visit official website at
http://www.geniatech.com
Contents
1. Safety Information,
1.1 Warning, P3
1.2 Precautions, P3-4
1.3 Handling Cautions, P4
P3-4
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATV598MAX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Geniatech ATV598MAX

Summary of Contents for Geniatech ATV598MAX

  • Page 1 ANDRIOD TV QUAD CORE BOX ATV598MAX User’s Guide Thank you for purchasing this Geniatech product. .Before using it, be sure to read the precautions contained in this User’s Guide. .Keep the User’s Guide in a safe place for future reference.

  • Page 2: Table Of Contents

    2. Introduction, P5-15 2.1 Package Contents, P5 2.2 Product Features, P5 2.3 Panel Introduction, P6 2.4 Remote Controller, P7 2.5 Setup Connection, P8 2.6 Display when Power Up, P8-15 3. Settings , P15-21 3.1 WiFi, P16 3.2 Bluetooth, P16 3.3 Ethernet, P17 3.4 Sound, P18 3.4.1 System Sound, P18 3.4.2 Surround Sound,P18...
  • Page 3 1. Safety Information Read and understand all instructions before using this product. If damage is caused by failure to follow the instructions, the warranty does not apply. 1.1 Warning To reduce the risk of electric shock, DO NOT remove the cover (or back). DO NOT attempt to repair the product, this could lead to the risk of injury, damage to the product .
  • Page 4 convenience receptacles, and the point where it exits the apparatus. 1.2.10 Only use attachments/accessories specified by the manufacturer. 1.2.11 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used , use caution when moving the cart/apparatus combination to avoid injury from tip-over.

  • Page 5: Introduction

    2. Introduction 2.1 Package Contents Enjoy TV Quad Core Box - ATV598MAX black User’s Guide HDMI Cable BT Remote Controller Optional Remote Controller 2.4G wireless Remote Controller USB wire/wireless Mouse & Keyboard Power Adapter, Input: AC100 ~ 240V, 50/60Hz, Output: 5V, 2A 2.2 Product Features...

  • Page 6: Panel Introduction, P6

    2.3 Panel Introduction...

  • Page 7: Remote Controller, P7

    2.4 Remote Controller Note: Button Battery 2025 3V insert with correct polarity (+/-).

  • Page 8: Setup Connection, P8

    2.5 Setup Connection Place ATV598MAX on a flat platform near the TV, and make sure nothing block the remote control signal. 2.6 Display when Power Up 2.6.1 After power up The TV will first show Geniatech logo,starting with Enjoy TV boot animation. When finished, it will go to Home screen.
  • Page 9 ATV598Max for you to use. First you should select a system language. 2.6.4 Setup Wizard - Setup with Android phone or tablet You can easily setup ATV598Max if you have an Android phone or tablet, or you can select No to continue the setup.
  • Page 10 2.6.5 Setup Wizard - Wi-Fi Setup Here you can connect ATV598Max to your home Wi-Fi router. If your home Wi-Fi router requires password, you will need to enter the correct password.
  • Page 11 2.6.6 Setup Wizard - Check for updates After connected to the network, ATV598Max will connect to the internet and check to see if there is update available. If update is available, ATV598Max will prompt you to update.
  • Page 12 2.6.7 Setup Wizard – Google account Here you will be asked to login your Google account, you can use your phone or enter your email address & password to login.
  • Page 13 2.6.8 Setup Wizard -Terms of Service To continue, you will need to agree to the Google Terms of Service and Privacy Policy. You can view the detail terms by selecting the corresponding terms. 2.6.9 Setup Wizard – Share Location You can select Yes or No to let Google and third party apps to use your location or not.
  • Page 14 2.6.10 Setup Wizard – Help improve Android TV You can select Yes or No to let Google to collect usage data from ATV598Max. 2.6.11 Home Screen display.

  • Page 15: Settings

    3. Settings Using Navigation (4 directions), OK, EXIT, and Menu keys of Remote Controller to select the options, the option selected will be highlighted and confirmed by pressing OK key. Same operation for text input if needed. Select icon then press OK key to settings interface.
  • Page 16 Or fail to connect and need reset password. 3.1.3 Once build up the connection with a certain WiFi network successfully, ATV598MAX will connect this WiFi network automatically when restart. Note: If factory reset, the password of WiFi network have to be reset. 3.2 Bluetooth...

  • Page 17: System Sound, P18

    3.3 Ethernet Connect Box and Router by RJ45 network cable. Press “ OFF” in WiFi setting, it will connect to network automatically. 3.4 Sound 3.4.1 System Sound Turn on or off system sounds. 3.4.2 Surround Sounds You can setup Surround sound to auto, on or off.

  • Page 18: Storage & Reset, P18-19

    3.5 Display 3.5.1 Screen resolution You can select different screen resolution here, by default it is set to auto switch to best resolution for your TV. You can also setup different color space and turn on or off Dolby Vision function. 3.5.2 Screen position Here you can change the scaling of the screen, different TV has different scaling, you can use Zoom in/out to make the screen fit for your TV.
  • Page 19 3.6.1Factory data reset This will erase all data from your ATV598Max’s internal storage, including: • Your Google account • System and app data and settings • Downloaded apps • Music\Photos • Other user data You can reset all the settings and apps to factory default.

  • Page 20: Language & Input, P20

    3.8 Security & restrictions 3.9 Language & input Change OSD language and input method. The default input method is android standard keyboard. If you are using our IR remote control, enter into “Default” option and switch to remote controller input method.

  • Page 21: About Device, P21

    3.10 About device 4.DTV Player 4.1. Scan for TV Channels First make sure you have plug in the RF antenna. For first time usage,you can select the DTV Player from APPS. First Select Login Online EPG or Skip intoAuto SEARCH Window, and in the Area section, select your country.
  • Page 22 After you have chosen the correct Area, you can Auto Scan to start scanning for channels. ATV598MAX will scan the whole frequency range for TV channels, and will list out all found channels. You can exit anytime during the scanning, the found channels...

  • Page 23: Dtv Functions,P23-24

    4.2. DTV Functions You can press the Left button to bring up the channel list, in there you can press more Left button select TV channels, Radio channels or your favorite channels. You can press OK button to bring up the TV sub menu, from the menu you can see the TV information.

  • Page 24: Dtv Player Settings,P24-27

    You can press Right button to bring up the Popup Menu, from the popupmenu you can Easy setup control. 4.3. DTV Player settings You can press OK button twice to bring up the Settings, from the menu you can try Settings.
  • Page 25 4.3.2.Channel list In Channel list , you can check TV shows schedule for the coming 7 days, and also can setup schedule recording. you can select which device to store the recorded files. You can also change the Timeshift size to select how long the timeshift should be. In PVR list, all recorded files will be list here, you can playback the file, delete the file or format the storage device.
  • Page 26 4.3.4. Settings Select Settings , you can setting recall list, closed caption, recorded videos, set password,TTX region,factory data reset,parental rating age,setup wizard, setup wizard. Under Settings menu, there are: Recall List: Select which recall list to be use Closed caption:On/off caption Recorded videos:See the recorded videos list Set password: Change the password for program edit and parental rating age, they use the same password.

  • Page 27: Apps Install & Uninstall

    TV channel logo: Set the TV channel logo display or hide 5. Apps Install & Uninstall On ATV598MAX, you can install apps from Android Market over the Internet or other sources, such as other online sources, the internal storage and the USB storage device and SD card that you have mounted onto ATV598MAX.

  • Page 28: Repairs

    We will provide you with the amount of the administration fee before we make a home visit or begin any work on your player. We recommend you read this manual throughly, search for a solution on line at www.geniatech.com, or contact Geniatech Customer Care before seeking to repair your player.

  • Page 29: Specification

    9. Specification Quad Core ARM Cortex-A53 CPU up to @ 2.0GHz Penta-core ARM Mali-450 GPU up to 750MHz 2GB DDR (Optional 1GB DDR) built in 16G EMMC Android 7.1 OS Optional DOLBY USB2.0 x 2 HDMI V2.0a DC Input 5.0V-2.0A SD Slot Max: 256GB Video Output...

  • Page 30: Trademark Notice

    Size 115x114 x 27mm Net Weight 250g IR Remote Controller Optional BT Remote controller 2.4G wireless Remote Controller with Nano receiver Optional Remote Controller USB wire/wireless Mouse & Keyboard AC100 ～ 240V 50/60Hz Power Adapter 10. Trademark Notice The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in United States and other countries.
