ENJOY TV DUAL CORE ATV3200 User’s Guide Thank you for purchasing this Geniatech product. .Before using it, be sure to read the precautions contained in this User’s Guide. .Keep the User’s Guide in a safe place for future reference. .For the most up-to-date information about this product, visit official website at...
1. Safety Information Read and understand all instructions before using this product. If damage is caused by failure to follow the instructions, the warranty does not apply. 1.1 Warning To reduce the risk of electric shock, DO NOT remove the cover (or back). DO NOT attempt to repair the product, this could lead to the risk of injury, damage to the product .
plugs, convenience receptacles, and the point where it exits the apparatus. 1.2.10 Only use attachments/accessories specified by the manufacturer. 1.2.11 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used , use caution when moving the cart/apparatus combination to avoid injury from tip-over.
⑦ Downwards ⑰ Page Down ⑧ OK ⑨ Return Note: Button Battery 2025 3V insert with correct polarity (+/-). 2.5 Setup Connection Place ATV3200 on a flat platform near the TV, and make sure nothing block the remote control signal.
HDD Installation and Uninstallation 2.6 Display when Power Up 2.6.1 After power up, the TV will first show a green robot then change to “android” logo during loading. When loading is finished, it will go to Home screen. 2.6.2 Home Screen display.
3. Settings Using Navigation (4 directions), OK, EXIT, and Menu keys of Remote Controller to select the options, the option selected will be highlighted and confirmed by pressing OK key. Same operation for text input if needed. Select icon then press OK key. 3.1 WiFi 3.1.1 It will automatically scan ambient WiFi networks when select “ON”.
3.3 Date usage Show data usage information. 3.4 More... 3.4.1 VPN Build and set VPN...
Page 11
3.4.2 Tethering & Portable hotspot 3.4.3 Proxy settings Setup proxy server 3.5 Sound 3.6 Display 3.6.1 Font size Change the font size of OSD...
Page 12
3.6.2 Wireless display 3.7 Storage Shows the storage used of the OS and SD card. 3.8 Apps List all apps installed.
Page 13
You can choose an application and force to shut down the app, uninstall the app, clear user data, move to SD card and clear cache data. 3.9 Location access...
3.10 Security 3.11 Language & input Change OSD language and input method. The default input method is android standard keyboard. If you are using our IR remote control, enter into “Default” option and switch to remote controller input method.
3.12 Backup & reset Back up my data: You can backup your application data, WiFi password and other settings. Factory data rest: You can reset all the settings and apps to factory default. Note: You might want to backup important data before resetting the box. Once you choose to rest to factory default, all data/apps will be deleted.
3.16 Developer options If user want to do some debugging on box by ADB, enable USB debugging, you will get ADB function by Ethernet or WiFi network. 3.17 About device. Firmware version under build number.
4. Apps Install & Uninstall On ATV3200, you can install apps from Android Market over the Internet or other sources, such as other online sources, the internal storage and the USB storage device and SD card that you have mounted onto ATV3200.
8. Specification Dual core ARM CORTEX A9 1.5GHz, 3D engine Mali 400MP2 @400MHz 1G DDR3 4G, built in 2G-32G Flash memory(optional) Android 4.2 OS Ex-SD Max. 32G USB2.0 x4 , Support Mobile HDD, wired/wireless mouse and keyboard Mini USB Mini USB 2.0 x1 HDMI V1.4a DC Input...
9. Trademark Notice The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in United States and other countries.
