Android Box
ENJOY TV OCTA CORE BOX
ATV1960
User's Guide
Thank you for purchasing this Geniatech product.
.Before using it, be sure to read the precautions contained in this User's Guide.
.Keep the User's Guide in a safe place for future reference.
.For the most up-to-date information about this product, visit official website at
http://www.geniatech.com
1
Advertisement
Table of Contents
Related Manuals for Geniatech ATV1960
Summary of Contents for Geniatech ATV1960
- Page 1 ENJOY TV OCTA CORE BOX ATV1960 User’s Guide Thank you for purchasing this Geniatech product. .Before using it, be sure to read the precautions contained in this User’s Guide. .Keep the User’s Guide in a safe place for future reference.
-
Page 2: Table Of Contents
Contents 1. Safety Information, P3-4 1.1 Warning, P3 1.2 Precautions, P3-4 1.3 Handling Cautions, P4 2. Introduction, P5-8 2.1 Package Contents, P5 2.2 Product Features, P5 2.3 Panel Introduction, P6 2.4 Remote Controller, P6 2.5 Setup Connection, P7 2.6 Display when Power Up, P7-8 3. -
Page 3: Safety Information
1. Safety Information Read and understand all instructions before using this product. If damage is caused by failure to follow the instructions, the warranty does not apply. 1.1 Warning To reduce the risk of electric shock, DO NOT remove the cover (or back). DO NOT attempt to repair the product, this could lead to the risk of injury, damage to the product . -
Page 4: Handling Cautions, P4
convenience receptacles, and the point where it exits the apparatus. 1.2.10 Only use attachments/accessories specified by the manufacturer. 1.2.11 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used , use caution when moving the cart/apparatus combination to avoid injury from tip-over. -
Page 5: Introduction
2. Introduction 2.1 Package Contents Enjoy TV Octa Core Box - ATV1960 black User’s Guide HDMI Cable IR Remote Controller (IR RC) Optional Remote Controller 2.4G wireless Remote Controller USB wire/wireless Mouse & Keyboard Power Adapter, Input: AC100 ~ 240V, 50/60Hz, Output: 5V, 3A 2.2 Product Features... -
Page 6: Panel Introduction, P6
2.3 Panel Introduction 2.4 Remote Controller ⑩ Home ① Power ⑪ Background App ② Mode ⑫ Menu ③ Mute ⑬ Vol+ ④ Upwards ⑭ Notification ⑤ Towards the left ⑮ Page Up ⑥ Towards the right ⑯ Vol- ⑦ Downwards ⑰... -
Page 7: Setup Connection, P7
2.5 Setup Connection Place ATV1960 on a flat platform near the TV, and make sure nothing block the remote control signal. 2.6 Display when Power Up 2.6.1 After power up, the TV will first show a green robot during loading. When... - Page 8 2.6.2 Home Screen display.
-
Page 9: Settings
3. Settings Using Navigation (4 directions), OK, EXIT, and Menu keys of Remote Controller to select the options, the option selected will be highlighted and confirmed by pressing OK key. Same operation for text input if needed. Select icon then press OK key to settings interface. Or Select icon to settings interface. - Page 10 Or fail to connect and need reset password. 3.1.3 Once build up the connection with a certain WiFi network successfully, ATV1960 will connect this WiFi network automatically when restart. Note: If factory reset, the password of WiFi network have to be reset. 3.2 Bluetooth...
-
Page 11: More
3.3 Ethernet Connect Box and Router by RJ45 network cable. Press “ ON” in WiFi Ethernet setting, it will connect to network automatically. 3.4 More... -
Page 12: Sound And Notification, P12-13
3.4.1 VPN Edit VPN profile 3.4.2 Portable hot spot 3.4.2.1 Enable Portable hot spot 3.4.2.2 Set up WiFi hot spot WiFi and hot spot connection can not be applied at same time. Disconnect WiFi and connect Ethernet while using hot spot function. 3.5 Sound and notification 3.5.1 Sound Increase or decrease sound volumes... - Page 13 3.5.2 Other Sounds Choose Other sounds,you can set Click sounds , if enable Click sounds, sound will be heard while move remote controller. 3.6 Display...
- Page 14 Change the font size of OSD 3.7 Storage and USB Shows the storage used of the OS and SD card.
- Page 15 3.8 Apps List all apps installed. You can choose an application and force to shut down the app, uninstall the app, clear user data, move to SD card and clear cache data. 3.9 Memory...
- Page 16 3.10 Location 3.11 Security...
- Page 17 3.12 Accounts...
-
Page 18: Language & Input, P17
3.13 Google 3.14 Language & input Change OSD language and input method. The default input method is android standard keyboard. If you are using our IR remote control, enter into “Default” option and switch to remote controller input method. -
Page 19: Date Time, P19
3.15 Reset Factory data rest: You can reset all the settings and apps to factory default. Note: You might want to backup important data before resetting the box. Once you choose to rest to factory default, all data/apps will be deleted. 3.16 Date time... -
Page 20: About Device, P20
3.17 About device... -
Page 21: Apps Install & Uninstall
4. Apps Install & Uninstall On ATV1960, you can install apps from Android Market over the Internet or other sources, such as other online sources, the internal storage and the USB storage device and SD card that you have mounted onto ATV1960. -
Page 22: Firmware Update
5. Firmware Update You can download newest firmware from Geniatech Official website: www.geniatech.com... -
Page 23: Trouble Shooting/Faq
6. Trouble Shooting/FAQ 6.1 No Picture Refer to the TV user manual for how to select the correct video input channel. 6.2 USB Content cannot be read . The format of USB storage device is not supported . The supported memory size is 33G maximum. . -
Page 24: Repairs
We will provide you with the amount of the administration fee before we make a home visit or begin any work on your player. We recommend you read this manual throughly, search for a solution on line at www.geniatech.com, or contact Geniatech Customer Care before seeking to repair your player. -
Page 25: Specification
8. Specification Octa Core ARM Cortex-A53 CPU up to @ 2.0GHz Mali-T820MP3 GPU @ 750MHz+(DVFS) 3G DDR4 16G EMMC 2.5" Internal HDD Android 6.0 OS Optional DOLBY USB2.0 x2 HDMI V2.0a DC Input 5.0V-3A SD Slot Max: 33G Video Output HDMI/CVBS Audio Output HDMI/CVBS... -
Page 26: Trademark Notice
9. Trademark Notice The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in United States and other countries.
