Empire DVCT36-CF Installation Instructions Manual
  1. Manuals
  2. Brands
  3. Empire Manuals
  4. Indoor Fireplace
  5. DVCT36-CF
  6. Installation instructions manual

Empire DVCT36-CF Installation Instructions Manual

Direct-vent zero clearance gas fireplace heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch;
do not use any phone in your building.
•
Leave the building immediately.
•
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
•
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
DANGER
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk
individuals.
INSTALLATION INSTRUCTIONS
(SEE HOMEOWNER MANUAL FOR OPERATING INSTRUCTIONS)
WILL
HOT GLASS
CAUSE BURNS.
DO NOT TOUCH
GLASS
UNTIL COOLED.
NEVER
ALLOW CHILDREN
TO TOUCH GLASS.
DIRECT - VENT ZERO
CLEARANCE GAS FIREPLACE
HEATER MODEL SERIES:
DVCT36CBP95(N,P)-2
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
DVCT40CBP95(N,P)-2
GAS-FIRED
UL FILE NO. MH30033
This fireplace is design
certified in accordance
with American National
Standard/CSA Standard
ANSI Z21.88/CSA 2.33
and by Underwriters
Laboratories as a Direct
Vent Gas Fireplace
Heater and shall be
installed according to
these instructions.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVCT36-CF and is the answer not in the manual?

Questions and answers

Related Manuals for Empire DVCT36-CF

Summary of Contents for Empire DVCT36-CF

  • Page 1 INSTALLATION INSTRUCTIONS (SEE HOMEOWNER MANUAL FOR OPERATING INSTRUCTIONS) DIRECT - VENT ZERO INSTALLER: Leave this manual with the appliance. CLEARANCE GAS FIREPLACE CONSUMER: HEATER MODEL SERIES: Retain this manual for future reference. DVCT36CBP95(N,P)-2 DVCT40CBP95(N,P)-2 WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
