WARNING:
Repeated assembly can weaken the locking ability of the screw/bolt/nut. Periodically check all bolted connections
on your product to make sure they are tight and secure. Keep these instructions for future reference.
Some parts may contain sharp edges. Wear protective gloves as necessary.
Set it up on the level ground.
Attention: There are pre-crack slots on the back side of the log, this is not inferior, and the slot is
pre-drilled and intended produced, this is to allow the wood to naturally shrink and expand.
Parts List
Part
Description
A
Table Plate
B
Leg
C
Connection
D
Beam
AA
M4*40 Screw
Assembly Instructions
D-BS950SWD-T
Qty.
1
4
2
1
20
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sunjoy D-BS950SWD-T
Summary of Contents for Sunjoy D-BS950SWD-T
- Page 1 Assembly Instructions D-BS950SWD-T WARNING: Repeated assembly can weaken the locking ability of the screw/bolt/nut. Periodically check all bolted connections on your product to make sure they are tight and secure. Keep these instructions for future reference. Some parts may contain sharp edges. Wear protective gloves as necessary.
- Page 2 Step 1: Insert Connection(C) into the hole of Leg (B). Step 2: Attach Connection(C) to Leg (B) with Screw AA (Don’t fasten screw now). Step 3: Turn over the assembled Connection(C) and Leg Step 4: Attach Connection(C) to Beam (D) with Screw AA (Don’t fasten screw now).
- Page 3 Limited Warranty: This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the item is maintained with care and used only for personal, residential purposes. The item is warranted to be free from defects in material or workmanship for a period of six (6) months.
