Model No. WESY19720
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you have
questions, or find there are miss-
ing or damaged parts, we will
guarantee you complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Visit our website at
Read all precautions and instruc-
www.weiderfitness.com
tions in this manual before using
this equipment. Save this manual
new products, prizes,
for future reference.
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WESY19720 and is the answer not in the manual?

Questions and answers

Related Manuals for Weider WESY19720

Summary of Contents for Weider WESY19720

  • Page 1 Model No. WESY19720 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or find there are miss-...

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............Back Cover Note: A PART IDENTIFICATION CHART is attached to the center of this manual. Remove the PART IDENTIFICATION CHART before beginning assembly. WEIDER is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING : To reduce the risk of serious injury, read the following important precautions before using the weight system. 1. Read all instructions in this manual and in 12. Always disconnect the lat bar from the the accompanying literature before using the weight system when performing an exercise weight system.

  • Page 4: Before You Begin

    The model number is WESY19720. The size and strength, or improve your cardiovascular sys- serial number can be found on a decal attached to the...

  • Page 5: Assembly

    ASSEMBLY Before beginning assembly, carefully read the • As you assemble the weight system, be sure that following information and instructions: all parts are oriented as shown in the drawings. • Place all parts of the weight system in a cleared •...
  • Page 6 2. Slide the Front Upright (42) onto the M8 x 63mm Carriage Bolts (1) in the Base (4). Hand tighten an M8 Nylon Locknut (3) onto each Carriage Bolt. Do not tighten the Nylon Locknuts yet. Press a 1” Square Inner Cap (65) into the Front Upright (42).
  • Page 7 5. Press the Weight Tube Bumper (64) into the end of the Weight Tube (63). Insert the Holes Weight Tube into the stack of Weights (25). Be sure that the pins on the Weight Tube are aligned with the pin grooves in the upper Weight.
  • Page 8 8. Press a 1 3/4” Square Inner Cap (44) into the top of a Press Arm (46). Press a 1” Round Inner Cap (49) into each end of the handle on the Press Arm. Attach the Press Arm to one side of the Press Frame (17) with two M8 x 62mm Bolts (22) and two M8 Nylon Locknuts (3).
  • Page 9 11. During steps 11 through 25, refer to the CABLE DIAGRAM on page 20 of this manual to verify proper cable routing. Before begin- ning this section, identify the Long Cable (23) and the Short Cable (58) by comparing the lengths of the cables.
  • Page 10 15. Route the Long Cable (23) around the “V”- Pulley (6) on the Right Arm (48). Be sure that the Cable is in the groove of the “V”- Pulley and that the Long Cable Trap (50) is turned to hold the Cable in place. Tighten the M10 x 60mm Bolt (7) and the M10 Nylon Locknut (not shown).
  • Page 11 19. Loosen the M10 Nylon Locknut (21) on the lower 3 1/2” Pulley (15) on the Press Frame (17). Locate the Short Cable (58). Route the Short Cable (58) under the 3 1/2” Pulley (15). Be sure that the end of the Cable with the ball is on the indicated side of the Press Frame (17) and that the Cable is between the Pulley and the crossbar on the Press...
  • Page 12 21. Route the Short Cable (58) around the 3 1/2” Pulley (15) attached to the upper hole in the Press Frame (17). Be sure that the Cable Trap (66) is turned to hold the Cable in place and that the Cable is routed around the Pulley as shown.
  • Page 13 23. Attach the end of the Short Cable (58) to the Long “U”-Bracket (57) with an M8 Nylon Lock- nut (3) and a 5/16” Flat Washer (8). Do not completely tighten the Nylon Locknut. It should be threaded onto the end of the Cable so only a couple of threads are showing above the nut, as shown in the inset drawing.
  • Page 14 25. Attach the Backrest (41) to the Front Upright (42) with two M6 x 65mm Screws (43) and two 1/4” Flat Washers (10). 26. Press a 1 1/2” Square Inner Cap (32) into the Seat Frame (36). Insert the M6 x 50mm Carriage Bolt (38) into the center hole in the Seat Plate (37).
  • Page 15 28. Rest the Seat Frame (36) on the indicated pin in the Front Upright (42). Attach the Seat Frame to the Front Upright with a M8 x 67mm Carriage Bolt (14) and the Seat Knob (40). 29. Press 3/4” Round Inner Caps (34) into the ends of both 12 1/2”...
  • Page 16 30. Remove the decals from the decal sheet (not shown) and apply them to the weight system in the locations shown below. HIGH PULLEY BUTTERFLY 8515 BENCH PRESS LEG EXTENSION LEG CURL LOW PULLEY 31. Make sure that all parts have been properly tightened. The use of the remaining parts will be explained in ADJUSTMENTS, beginning on page 17 of this manual.

  • Page 17: Adjustments

    ADJUSTMENTS The instructions below describe how each part of the weight system can be adjusted. Refer to the exercise guide accompanying this manual to see how the weight system should be set up for each exercise. IMPOR- TANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the correct start- ing position for the exercise to be performed.
  • Page 18 ATTACHING AND REMOVING THE SEAT Set the bracket on the Seat Frame (36) onto the indi- cated pins on the Front Upright (42). Attach the Seat Frame to the Front Upright with the M8 x 67mm Carriage Bolt (14) and the Seat Knob (40). For some exercises, the Seat (13) must be removed.

  • Page 19: Troubleshooting And Maintenance

    TROUBLESHOOTING AND MAINTENANCE Make sure all parts are properly tightened each time the weight system is used. Replace any worn parts immedi- ately. The weight system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used.

  • Page 20: Cable Diagram

    CABLE DIAGRAM The cable diagram below shows the proper routing of the Short Cable (58) and the Long Cable (23). Use the diagram to be sure that the two cables and the cable traps have been assembled correctly. If the cables have not been correctly routed, the weight system will not function properly and damage may occur.
  • Page 21 NOTES...

  • Page 22: Part List

    PART LIST—Model No. WESY19720 R0902A Key No. Qty. Description Key No. Qty. Description M8 x 63mm Carriage Bolt Backrest M6 Nylon Locknut Front Upright M8 Nylon Locknut M6 x 65mm Screw Base 1 3/4” Square Inner Cap Stabilizer 10” Pad “V”-Pulley...

  • Page 23: Exploded Drawing

    EXPLODED DRAWING—Model No. WESY19720 R0902A...

  • Page 24: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: 1. The MODEL NUMBER of the product (WESY19720) 2. The NAME of the product (WEIDER ®...
  • Page 25 This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below each part refers to the key number of the part from the PART LIST on page 22 of this manual. Important: Some parts may have been pre-assembled for shipping purposes.
  • Page 26 PART IDENTIFICATION CHART—Model No. WESY19720 R0902A M6 Nylon Locknut (2)–1 M6 x 50mm Screw (24)–1 M8 Nylon Locknut (3)–19 M6 x 65mm Screw (43)–2 M10 Nylon Locknut (21)–12 M8 x 45mm Bolt (72)–1 1/4" Flat Washer (10)–4 M8 x 57mm Bolt (33)–1 5/16"...
  • Page 28 3/4" Round Inner Cap (34)–4 1" Round Inner Cap (49)–6 1" Round Cover Cap (70)–2 1/2" x 3/4" Spacer (61)—2 5/8" x 9/16" Spacer (73)–1 1" Square Inner Cap (65)—1 M8 x 50mm Eyebolt (35)—1 1 3/4" Square Inner Cap (44)–6 1 1/2"...
