Model No. WESY17011
Serial No.
(Write the serial number in the
space above for reference.)
Serial Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WESY17011 and is the answer not in the manual?

Questions and answers

Related Manuals for Weider WESY17011

Summary of Contents for Weider WESY17011

  • Page 1 Model No. WESY17011 Serial No. (Write the serial number in the space above for reference.) Serial Number Decal (under seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............Back Cover Note: A PART IDENTIFICATION CHART is attached in the center of this manual. WEIDER is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight system. 1. Read all instructions in this manual and in the accompanying literature before using the weight system. 2. It is the responsibility of the owner to ensure that all users of the weight system are ade- quately informed of all precautions.

  • Page 4: Before You Begin

    To help us assist you, please note the product model number and serial number before calling. The model ® number is WESY17011. The serial number can be found on a decal attached to the weight system (see the front cover of this manual).

  • Page 5: Assembly

    ASSEMBLY Make Assembly Easier for Yourself Everything in this manual is designed to ensure that the weight system can be assem- bled successfully by anyone. Before begin- ning assembly, make sure to read the information on this page. This brief intro- duction will save you much more time than it takes to read it.

  • Page 6: Frame Assembly

    FRAME ASSEMBLY 1. Before beginning assembly, be sure that you have read and understand the information in the box on the previous page. Press a 50mm Square Outer Cap (51) onto each end of the Stabilizer (5). Press a 50mm Square Inner Cap (27) into the end of the Base (4).

  • Page 7: Arm Assembly

    3. Press a 45mm Square Inner Cap (44) into each end of the crossbar on the Top Frame (55). Press two 25mm Round Inner Caps (49) into the top of the crossbar. Press a 50mm Square Inner Cap (27) into the top of the Rear Upright (56). Attach the Top Frame (55) to the Front Upright (42) with a Support Plate (68), two M8 x 67mm Bolts (61), and two M8 Nylon Locknuts (3).

  • Page 8: Cable Assembly

    7. Lubricate both axles on the Top Frame (55). Slide the Right Arm (48) onto the right axle. Note: Be careful not to confuse the Right Arm with the Left Arm (47); refer to step 6 to identify the Right Arm. Be sure that the upper end of the Right Arm is behind the indicated bracket on the Top Frame.
  • Page 9 10. Wrap the Long Cable (58) around a “V”-Pulley (6). Attach the “V”-Pulley and a Long Cable Trap (50) to the indicated bracket on the Front Upright (42) with an M10 x 60mm Bolt (7) and an M10 Nylon Locknut (21). Be sure that the Long Cable Trap is positioned to hold the Cable in place.
  • Page 10 14. Locate the Long “U”-Bracket (57) that is pre- assembled with a 90mm Pulley (15) and a Cable Trap (not shown). Route the Long Cable (58) around the Pulley and through the Long “U”- Bracket. Be sure that the Cable is in the groove of the Pulley, that the Cable Trap is turned to hold the Cable in place, and that the Cable and Pulley move smoothly.
  • Page 11 17. Using an M10 x 80mm Bolt (25), an M10 Washer (9), and an M10 Nylon Locknut (21), secure a 90mm Pulley (15) and a Cable Trap (66) to the upper hole in the Press Frame (17). Make sure that the Cable Trap and the Pulley are oriented as shown.
  • Page 12 21. Route the Short Cable (23) up around the 90mm Pulley (15) attached to the upper hole in the Press Frame (17). Be sure that the Cable is routed around the Pulley as shown, and that the Cable Trap (66) is turned to hold the Cable in place.

  • Page 13: Seat Assembly

    SEAT ASSEMBLY 23. Attach the Backrest (41) to the Front Upright (42) with two M6 x 63mm Screws (43) and two M6 Washers (10). 24. Press a 38mm Square Inner Cap (32) into the Seat Frame (36). Insert an M6 x 50mm Carriage Bolt (38) into the center hole in the Seat Plate (37).
  • Page 14 26. Rest the Seat Frame (36) on the indicated pin in the Front Upright (42). Attach the Seat Frame to the Front Upright with an M8 x 67mm Carriage Bolt (14) and the Seat Knob (40). 27. Press 19mm Round Inner Caps (34) into the ends of both Pad Tubes (28).
  • Page 15 28. Attach the Curl Pad (72) to the Curl Post (71) with two M6 x 16mm Screws (18). 29. Slide two Handgrips (31) onto the ends of the Lat Bar (54). 30. Make sure that all parts have been properly tightened. The use of all remaining parts will be explained in ADJUSTMENTS, beginning on the following page.

  • Page 16: Adjustment

    ADJUSTMENT The instructions below describe how each part of the weight system can be adjusted. Refer to the exercise guide accompanying this manual to see how the weight system should be set up for each exercise. IMPOR- TANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the correct start- ing position for the exercise to be performed.
  • Page 17 ATTACHING THE LEG LEVER TO THE LOW PULLEY STATION To use the Leg Lever (29), the seat must be attached to the front upright (see ATTACHING AND REMOV- ING THE SEAT on page 16). Attach the Short Cable (23) to the M10 Eyebolt (35) with a Cable Clip (53).

  • Page 18: Weight Resistance Chart

    WEIGHT RESISTANCE CHART This chart shows the approximate weight resistance at each weight station. The column labeled “WEIGHT ON WEIGHT CARRIAGE” refers to the amount of weight, in pounds, placed on the weight carriage. The weight resistance shown for the butterfly arm station is for each butterfly arm. Note: The actual resistance at each station may vary due to friction between the cables, pulleys, and weight carriage.

  • Page 19: Trouble-Shooting And Maintenance

    TROUBLE-SHOOTING AND MAINTENANCE Make sure all parts are properly tightened each time you use the weight system. Replace any worn parts immedi- ately. The weight system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used.

  • Page 20: Cable Diagram

    CABLE DIAGRAM The cable diagram below shows the proper routing of the Short Cable (23) and the Long Cable (58). Use the dia- gram to be sure that the two cables and the cable traps have been assembled correctly. If the cables have not been correctly routed, the weight system will not function properly and damage may occur.
  • Page 21 NOTES...

  • Page 22: Part List

    PART LIST—Model No. WESY17011 Key No. Qty. Description M8 x 63mm Carriage Bolt M6 Nylon Locknut M8 Nylon Locknut Base Stabilizer “V”-Pulley M10 x 60mm Bolt M8 Washer M10 Washer M6 Washer M8 x 70mm Bolt M10 x 45mm Bolt...

  • Page 23: Exploded Drawing

    EXPLODED DRAWING—Model No. WESY17011 R0802B...
  • Page 24 PART IDENTIFICATION CHART—WESY17011 M6 Nylon Locknut (2) M8 Nylon Locknut (3) M10 Nylon Locknut (21) M6 Washer (10) M8 Washer (8) M10 Washer (9) Cable Clip (53) M6 x 16mm Screw (18) M6 x 50mm Screw (24) M6 x 50mm Carriage Bolt (38)
  • Page 25 M10 x 20mm Bolt (69) M10 x 45mm Bolt (12) M10 x 60mm Bolt (7) M8 x 67mm Bolt (61) M8 x 67mm Carriage Bolt (14) M8 x 70mm Bolt (11) M10 x 80mm Bolt (25) M10 x 90mm Bolt (16) M8 x 115mm Bolt (64)
  • Page 26 50mm Square Inner Cap (27) 50mm Square Outer Cap (51) 38mm Square Inner Cap (32) 45mm Square Inner Cap (44) 25mm Round Inner Cap (49) 25mm Square Inner Cap (65) 25mm Round Cover Cap (62) 19mm Round Inner Cap (34) 25mm Retainer (63)

  • Page 27: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information: • The MODEL NUMBER of the product (WESY17011) • The NAME of the product (WEIDER • The SERIAL NUMBER of the product (see the front cover of this manual) •...
