Model No. WESY13820
Model Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you have
questions, or if there are missing
parts, we will guarantee complete
satisfaction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE. The
technicians on our customer hot
line will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weider WESY13820
Summary of Contents for Weider WESY13820
- Page 1 Model No. WESY13820 Model Number Decal (under seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee complete satisfaction through direct assis- tance from our factory.
-
Page 2: Table Of Contents
Note: A PART IDENTIFICATION CHART and a PART LIST/EXPLODED DRAWING are attached in the center of this manual. Remove the PART IDENTIFICATION CHART and the PART LIST/EXPLODED DRAWING before beginning assembly. WEIDER is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the weight system. 1. Read all instructions in this manual and in the accompanying literature before using the weight system. Use the weight system only as described in this manual. -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the versatile WEIDER weight system. The WEIDER ® 950 weight system offers a selection of weight stations designed to devel- op every major muscle group of the body. Whether your goal is to tone your body, build dramatic muscle... -
Page 5: Assembly
ASSEMBLY Make Things Easier for Yourself Everything in this manual is designed to ensure that the weight system can be assembled suc- cessfully by anyone. However, it is important to realize that the versatile weight system has many parts and that the assembly process will take time. - Page 6 2. Press a 50mm Square Inner Cap (44) into the top of the Rear Upright (3). Attach the Rear Upright (3) to the Stabilizer (2) with the M8 x 67mm Carriage Bolts (66) and two M8 Nylon Locknuts (61). Attach the Front Upright (4) to the Base (1) with the two M8 x 63mm Carriage Bolts (65) and two M8 Nylon Locknuts (61).
-
Page 7: Arm Assembly
ARM ASSEMBLY 5. Press two 25mm x 50mm Inner Cap (42) into the top of the Press Frame (9). Press two 50mm Square Inner Caps (44) into the ends of the Press Frame. Orient the Press Frame (9) with the bracket on the side shown. -
Page 8: Cable Assembly
CABLE ASSEMBLY 8. Refer to the CABLE DIAGRAM on page 18 for proper cable routing. Locate the High Cable (35). Route the eyelet end of the Cable up through the Top Frame (5) and around a Pulley (39). Attach the Pulley inside the Top Frame with an M10 x 65mm Grade 5 Bolt (73), two M10 Washers (55), two M10 Spacers (74), and an M10 Nylon Locknut (56). - Page 9 11. Wrap the High Cable (35) around a Pulley (39). Attach the Pulley inside the bracket on the Top Frame (5) with an M10 x 45mm Bolt (68) and an M10 Nylon Locknut (56). 12. Attach the end of the High Cable (35) to the M10 x 20mm Bolt (75) in the bracket on the Weight Carriage (26) with an M10 Nylon Locknut (56).
- Page 10 15. Wrap the Arm Cable (36) around a Pulley (39). Attach the Pulley to the Double “U”-Bracket (15) with an M10 x 45mm Bolt (68) and an M10 Nylon Locknut (56). 16. Wrap the Arm Cable (36) around a “V”-Pulley (38).
- Page 11 19. Wrap the Short Cable (80) around a Pulley (39). Attach the Pulley to the Double “U”-Bracket (15) with an M10 x 45mm Bolt (68) and an M10 Nylon Locknut (56). 20. Attach the Short Cable (80) to the “U”-Bracket (81) with an M8 Washer (76) and an M8 Nylon Locknut (61).
- Page 12 23. Wrap the Low Cable (37) around a Pulley (39). Attach the Pulley and a Cable Trap (41) to the lower set of holes in the “U”-Bracket (81) with an M10 x 48mm Bolt (77) and an M10 Nylon Locknut (56).
-
Page 13: Seat Assembly
SEAT ASSEMBLY 27. Press two 38mm Square Inner Caps (48) into the ends of the Seat Frame (6) and the Leg Lever (7). Attach the Eyebolt (53) to the Leg Lever (7) with an M10 Washer (55) and an M10 Nylon Locknut (56). - Page 14 31. Slide a Pad Tube (21) through the hole in the Seat Frame (6). Slide two Small Foam Pads (20) onto the ends of the Pad Tube. Press two 19mm Round Inner Caps (49) into the ends of the Pad Tube.
-
Page 15: Adjustments
ADJUSTMENTS This section explains how to adjust the weight system. Refer to the accompanying exercise guide to see the cor- rect form for each exercise. Make sure all parts are properly tightened each time the weight system is used. Replace any worn parts immediate- ly. - Page 16 CONVERTING THE ARMS To use the Arms (10, 11) as butterfly arms, remove the Arm Pins (28) and engage the Arm Latch (29) into the hole in the Press Frame (9). To use the Arms (10, 11) as press arms, insert the two Arm Pins (28) into the holes in the Press Frame (9) and the Arms.
-
Page 17: Weight Resistance Chart
WEIGHT RESISTANCE CHART This chart shows the approximate weight resistance at each weight station. The column labeled “WEIGHT” refers to the amount of weight, in pounds, placed on the weight carriage. The weight resistance shown for the butterfly arm station is for each butterfly arm. Note: The actual resistance at each station may vary due to friction between the cables, pulleys, and weight carriage. -
Page 18: Cable Diagram
CABLE DIAGRAMS The cable diagrams below show the proper routing of the High Cable (35), the Arm Cable (36), the Low Cable (37), and the Short Cable (80). Use the diagrams to make sure that the cables and the cable traps have been assembled correctly. -
Page 19: Troubleshooting And Maintenance
TROUBLESHOOTING AND MAINTENANCE TIGHTENING THE CABLES Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used. If there is slack in the cables before resistance is felt, the cables should be tightened. Slack can be removed by moving a Pulley (39) and Cable Trap (41) to a set of holes closer to the center of the two Pulley Plates (14). - Page 20 PART IDENTIFICATION CHART—Model No. WESY13820 M10 Nylon Locknut (56) M8 Nylon Locknut (61) M6 Nylon Locknut (58) 25mm x 50mm Inner Cap (42) 38mm Square Inner Cap (48) 50mm Square Outer Cap (50) 19mm Round Inner Cap (49) 25mm Round Inner Cap (43)
- Page 21 M8 Washer (76) M6 x 16mm Bolt (59) M10 x 20mm Bolt (75) M6 x 43mm Bolt (57) M10 x 45mm Bolt (68) M10 x 48mm Bolt (77) M6 x 50mm Screw (64) M6 x 50mm Carriage Bolt (62) M10 x 55mm Bolt (69) M6 x 63mm Screw (70) M10 Washer (55) M6 Washer (63)
- Page 22 PART LIST—Model No. WESY13820 Key No. Qty. Description Base Stabilizer Rear Upright Front Upright Top Frame Seat Frame Leg Lever Curl Post Press Frame Right Arm Left Arm Lat Bar Nylon Strap Pulley Plate Double “U”-Bracket Backrest Seat Curl Pad...
- Page 23 EXPLODED DRAWING—Model No. WESY13820 39 56 R0902B...
-
Page 24: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: • The MODEL NUMBER of the product (WESY13820) • The NAME of the product (WEIDER •...
