P5514, P5514-V &
P5514-EP
Hydraulic Comparison Test Pump
Users Manual
PN 3952337
November 2010
© 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Summary of Contents for Fluke P5500 Series

  • Page 1 P5514, P5514-V & P5514-EP Hydraulic Comparison Test Pump Users Manual PN 3952337 November 2010 © 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
  • Page 3: Table Of Contents

    Table of Contents Title Page Preparation ......................1 How to Contact Fluke ..................1 Operating Fluid Compatibility................2 Safety Information ..................... 2 Compressed Liquid..................2 Personal Protective Equipment..............2 Symbols Used in this Manual ................2 Connections ....................... 3 Connect the Gauge ..................4 Connect the Test Port Insert ................
  • Page 4 P5514, P5514-V & P5514-EP Users Manual...
  • Page 5 List of Tables Table Title Page Operating Fluid Compatibility ................2 Symbols........................3 Test Port Insert - Parts List..................5 Seal Kit - Part Numbers ..................6 Screw Press Assembly - Parts List................. 10...
  • Page 6 P5514, P5514-V & P5514-EP Users Manual...
  • Page 7 List of Figures Figure Title Page Connecting the Gauge .................... 4 Test Port Insert ....................... 5 Reservoir and Test Port Assemblies............... 9 Screw Press Assembly ................... 9 Angle Adapter ......................11 Pointer Remover/Punch..................11...
  • Page 8 P5514, P5514-V & P5514-EP Users Manual...
  • Page 9: Preparation

    The comparison test pump should be mounted securely to a stable workbench or similar surface. Four mounting holes are provided in the pump stand for this purpose. How to Contact Fluke To order accessories, receive operating assistance, or get the location of the nearest Fluke distributor or Service Center, call: •...
  • Page 10: Operating Fluid Compatibility

    P5514, P5514-V & P5514-EP Users Manual Operating Fluid Compatibility The standard system is designed for use with a wide range of fluids; however, the O-ring seals are Nitrile; use of solvents, fuel oils, brake fluids or other, similar aggressive fluids can damage the seals.
  • Page 11: Connections

    Earth Ground Important Information: refer to manual Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information. Connections Fit the device under test (DUT) to the test port using the method described below:...
  • Page 12: Connect The Gauge

    P5514, P5514-V & P5514-EP Users Manual gjq001.eps Figure 1. Connecting the Gauge Connect the Gauge Refer to Figure 1 for steps 1 to 4. 1. Screw the appropriate gauge adapter fully on to the instrument to be tested. 2. Screw assembly down COUNTER-CLOCKWISE on to test port. Note Hand-tight is sufficient;...
  • Page 13: Operation

    Hydraulic Comparison Test Pump Operation gjq002.eps Figure 2. Test Port Insert Table 3. Test Port Insert - Parts List Item Description P5515 P5515-V P5515-EP O Ring 3865142 3865163 3867888 Test Port Insert 3919892 — — O Ring 3883397 3883521 3867895 Test Port 3918298 —...
  • Page 14: Operation

    P5514, P5514-V & P5514-EP Users Manual Operation W Warning Do not exceed the maximum working pressure of the instrument (stated on the instrument label). 1. Turn the screw press in to generate pressure. 2. Allow a few moments for the system to stabilize before taking any readings, especially after large changes in system pressure.
  • Page 15: Complete Disassembly

    Hydraulic Comparison Test Pump Maintenance and Servicing 4. The white, anti-extrusion ring (21) is a PTFE spiral, and can be removed by “unwinding” it from the rambler. 5. When removing the rambler seal (20), take care not to use any tool that may have a sharp edge that will scratch the surfaces of the rambler, otherwise it may leak when reassembled.
  • Page 16 P5514, P5514-V & P5514-EP Users Manual W Caution If the rambler shows signs of wear, then it is very likely that the main bore in the barrel is worn also. If the bore is worn or scratched, it will not seal correctly, and may leak under pressure.
  • Page 17 Hydraulic Comparison Test Pump Maintenance and Servicing gjq004.eps Figure 4. Screw Press Assembly...
  • Page 18 P5514, P5514-V & P5514-EP Users Manual Table 5. Screw Press Assembly - Parts List Part Item Description P5514 P5514-V P5514-EP Banjo Bolt 3918323 — — O Ring 3905652 3919393 3926936 Banjo Test Port 3918298 — — O Ring 3883397 3883521 3867895 O Ring 3864857...
  • Page 19: Ancillary Equipment

    Hydraulic Comparison Test Pump Ancillary Equipment Ancillary Equipment Angle Adapter, P5543 To calibrate gauges with the pressure connection on the rear (e.g. panel-mount gauges) in their correct position, an angle adapter should be used. The angle adapter fits directly onto the test station, converting it through 90 degrees, allowing the standard adapters to be used.
  • Page 20 P5514, P5514-V & P5514-EP Users Manual...
