Summary of Contents for VOLTCRAFT PH-410
- Page 1 Operating manual PH-410 pH Tester BNC connection Waterproof Precise and fast...
-
Page 2: Table Of Contents
Qualified personnel.......................... 9 Description ............................ 10 Scope of delivery .......................... 10 Job description............................ 10 The product at a glance ........................ 11 The PH-410 ............................ 11 Display elements .......................... 11 Operating elements .......................... 11 Connections............................ 12 Bases for measurement ........................ 13 pH measurement .......................... - Page 3 Table of contents 8.2.4 Adjustment of the measuring input ..................... 24 Error and system messages...................... 26 Disposal............................. 28 Technical data........................... 29 Service ............................... 30 12.1 Manufacturer............................ 30 B-H86.0.11.DB214-1.0 3 / 30...
-
Page 4: Legal Address Of The Manufacturer
1 | Legal address of the manufacturer PH-410 1 Legal address of the manufacturer Conrad Electronic SE Klaus-Conrad-Str. 1 D-92240 Hirschau http://www.conrad.com WEEE reg. no. DE 28001718 4 / 30 B-H86.0.11.DB214-1.0... -
Page 5: About This Documentation
PH-410 About this documentation | 2 2 About this documentation 2.1 Foreword Read this document carefully and familiarise yourself with the operation of the product before you use it. Keep this document ready to hand and in the immediate vicinity of the product so that it is available to the personnel/user for reference at all times in case of doubt. -
Page 6: Further Information
2 | About this documentation PH-410 Outcome of an action Result, consequence or effect of an instruction. Emphases In order to simplify legibility and provide a clearer overview, various sections / informa- tion are emphasised. – 1234 Display elements – Mechanical controls –... -
Page 7: Safety
PH-410 Safety | 3 3 Safety 3.1 Explanation of safety symbols DANGER This symbol warns of imminent danger which can result in death, severe bodily injury, or severe property damage in case of non-observance. DANGER This symbol indicates danger for living tissue as well as a variety of materials, which can be damaged or destroyed when coming into contact with this chemical. -
Page 8: Safety Instructions
3 | Safety PH-410 DANGER Incorrect area of application! In order to prevent erratic behaviour of the product, personal injury or property dam- age, the product must be used exclusively as described in the chapter Description [} p. 10] in the operating manual. -
Page 9: Intended Use
PH-410 Safety | 3 NOTE If the product is stored at a temperature above 50 °C, or is not used for an extended period of time, the batteries must be removed. Leaks from the batteries are avoided as a result. -
Page 10: Description
4 | Description PH-410 4 Description 4.1 Scope of delivery Please check to ensure the completeness of the product after opening the package. You should find the following components: – Quick reference guide – Handheld measuring device, ready for operation, including batteries –... -
Page 11: The Product At A Glance
PH-410 The product at a glance | 5 5 The product at a glance 5.1 The PH-410 LCD Display PH-410 BNC connection PH-410 5.2 Display elements Display Battery indicator Evaluation of the battery status Unit display Display of units, if applicable, with unstable symbol... -
Page 12: Connections
5 | The product at a glance PH-410 Up / Down button Press briefly Display of the min/max value Change value of the selected parameter Long press Reset the min/max value of the current measure- ment Both simultaneously Rotate display, overhead display... -
Page 13: Bases For Measurement
PH-410 Bases for measurement | 6 6 Bases for measurement 6.1 pH measurement 6.1.1 Explanation The pH value describes the acidic or alkaline behaviour of an aqueous solution. A pH value below 7 is acidic, a value above 7 is alkaline. A pH value of 7 is neutral. -
Page 14: Further Information
6 | Bases for measurement PH-410 6.1.4 Further information A pH electrode is a wear part. If the signal is very slow or the required values are no longer observed after careful cleaning and possible regeneration, the electrode must be replaced. When using the electrodes, be aware that various substances in aqueous solutions can corrode glass and that chemicals can produce a chemical reaction with the KCl solution in the electrode, which can result in blockage of the diaphragm. -
Page 15: Care And Maintenance
PH-410 Bases for measurement | 6 6.1.7 Care and maintenance NOTE The GAK 1400 working and calibration set includes all necessary products for calibra- tion, care and maintenance of the electrode. Normal cleaning takes place with the GRL 100 pepsin cleaning solution into which the electrode is immersed for 5 minutes before being rinsed off with clean water. -
Page 16: Maintenance
7 | Maintenance PH-410 7 Maintenance 7.1 Operating and maintenance notices NOTE The product and electrode must be handled with care and used in accordance with the technical data. Do not throw or strike. NOTE Plugs and sockets must be protected from soiling. -
Page 17: Calibration And Adjustment
PH-410 Maintenance | 7 – Only use high-quality and suitable alkaline batteries! CAUTION Damage! If the batteries have different charge levels, leaks and thus damage to the product can occur. – Use new, high-quality batteries! – Do not use different types of batteries! –... - Page 18 7 | Maintenance PH-410 For automatic calibration, open the Calibration menu. See Automatic pH calibration [} p. 19]. Prerequisite – The product is switched on. Instruction 1. Carefully remove the protective cap from the electrode. 2. Rinse off the electrode with distilled or deionised water.
- Page 19 PH-410 Maintenance | 7 – approx. 100 ml of distilled water – Buffer capsule Instruction Colour 10 °C 20 °C 25 °C 30 °C 40 °C GPH 4.0 Orange 3.99 3.99 4.01 4.01 4.03 GPH 7.0 Green 7.06 7.01 7.00 6.99...
- Page 20 7 | Maintenance PH-410 Outcome of an action After successful completion of the calibration the assessment of the electrode condi- tion is displayed briefly in percent. Then, the current measurement is shown in the dis- play again. A low value can be the result of the age of the electrode, contaminated or old buffer solutions or impurities on the BNC connector.
- Page 21 PH-410 Maintenance | 7 4. Enter the temperature of the buffer solution by pressing the Up key and Down key and confirm the entry by pressing the Function key again. 5. The PK.OF parameter appears in the display. 6. Place the electrode in the buffer solution with a value between pH 6.75 and pH 7.25.
-
Page 22: Operation
8 | Operation PH-410 8 Operation 8.1 Commissioning 8.1.1 Explanation Description The product is switched on with the On/Off button. It may be necessary to configure the product after switching on. See Configuration [} p. 22]. Prerequisite – Sufficiently full batteries are inserted in the product. -
Page 23: Configuring Parameters Of The Configuration Menu
PH-410 Operation | 8 3. By briefly pressing the Function key, you can scroll through the parameters. Select the parameter you would like to configure. 4. When you have selected the desired parameter, change the parameter to the de- sired value with the Up button and the Down button. -
Page 24: Adjustment Of The Measuring Input
8 | Operation PH-410 Temperature unit UN,T Temperature display in °C °( Temperature display in °F °F Shut-off time POFF No automatic shut-off Automatic shut-off after a selected time in minutes, 15 30 60 120 240 during which no buttons have been pressed... - Page 25 PH-410 Operation | 8 2. Press the On/Off button to switch on the product and open the Configuration menu. Release the Down button. The display shows the first parameter. 3. By briefly pressing the Function key, you can scroll through the parameters. Select the parameter you would like to configure.
-
Page 26: Error And System Messages
9 | Error and system messages PH-410 9 Error and system messages Display Meaning Possible causes Remedy Error during the last Faulty calibration Conduct a new calibration >(AL< calibration No display, Battery depleted Battery depleted Replace battery unclear char- System error... - Page 27 PH-410 Error and system messages | 9 Replace batteries Send in for repair B-H86.0.11.DB214-1.0 27 / 30...
-
Page 28: Disposal
10 | Disposal PH-410 10 Disposal NOTE The device must not be disposed of with household waste. If the product is disposed of, please take it to a municipal collection point, where it will be transported to a dis- posal company in accordance with requirements of hazardous goods laws. Otherwise, return it to us, freight prepaid. -
Page 29: Technical Data
PH-410 Technical data | 11 11 Technical data Measuring range pH 0.00 .. 14.00 pH Temperature compensation -5 .. 150 °C (or 23 .. 302 °F) Accuracy pH (device) ± 0.02 pH ± 1 digit Nominal temperature 25°C Input resistance pH ca. -
Page 30: Service
12 | Service PH-410 12 Service 12.1 Manufacturer If you have any questions, please do not hesitate to contact us: Contact VOLTCRAFT Distributed by Conrad Electronic SE Klaus-Conrad-Str. 1 92240 Hirschau, Germany Tel.: +49 9604 40 87 87 Fax: +49 180 5 312110 kundenservice@conrad.de...
