- Page 1 DN0994AOTX- Base DN0994BOTX - GLASS TOP ZINA DINING TABLE For assistance with assembly, contact： Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#: Page 1...
- Page 2 ZINA DINING TABLE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Carefully study the diagrams below. You may receive extra hardware with your unit. Quantity Quantity of 1 of 1 Glass top Side frame-B Quantity...
- Page 3 Quantity Quantity of 2 of 10 Spring washer Long bolt Dia 1/4”*2”L Quantity Quantity of 10 of 1 Metal plate Flat washer Quantity of 4 Glass pad Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth. Call Customer Service at 1-800-633-5096 Please call Manufacturer for assistance, questions Avoid rubbing or scratching the...
- Page 4 ZINA DINING TABLE Assembly Instructions Assembly Instructions: Wood may scratch easily. Be careful when assembling. Do not scratch. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page. Attached side frame (C) to side frame (B) by hand as shown.
- Page 5 Insert short bolt (2) and spring washer (4), flat washer (5) into pre-assembled unit on figure 2 of pre-drilled holes , Tighten bolt (2) by using Allen wrench (1) as shown. Now tighten all bolts at this time. Figure 3 Insert Glass pad (8) into pre-drilled holes on top frame as shown on figure 3.
- Page 6 Place glass top (A) on each Glass pad as shown in figure 5. Figure 5 Now your ZINA DINING TABLE is ready to use. Figure 6 Page 6...
- Page 7 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
