DN098700TX
Logan Dining Table
For assistance with assembly, contact:
Southern Enterprises, Inc.
Assembly Instructions
customer service 1-800-633-5096
service@seidal.com
www.seidal.com
PO#:
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Logan DN098700TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SEI Logan DN098700TX

  • Page 1 DN098700TX Logan Dining Table For assistance with assembly, contact: Southern Enterprises, Inc. Assembly Instructions customer service 1-800-633-5096 service@seidal.com www.seidal.com PO#: Page 1...
  • Page 2 Logan Dining Table Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
  • Page 3 Quantity Quantity of 1 of 8 allen wrench bolt: Dia 5/16” x 1-1/2”L Quantity Quantity of 8 of 8 spring washer flat washer Quantity Quantity of 4 of 2 long screw: 3/16” x 1-1/2”L screw: 3/16” x 1-1/4”L Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
  • Page 4 Logan Dining Table Assembly Instructions Turn top frame (A) upside-down on a soft working surface and insert the bolts (2) into the spring washers (3) and flat washers (4). Attach the right leg (C) to top frame (A) with bolts (2) and tighten all bolts (2) using allen wrench (1).
  • Page 5 Insert long screws (5) into pre-drilled holes on stretchers (D) as shown, and tighten using screwdriver. Figure 3 Insert screws (6) into pre-drilled holes on stretcher (E) as shown, and tighten using screwdriver. Figure 4 Page 5...
  • Page 6 Turn the table over. If the table is not level, please adjust the levelers on the end of the legs by hand as shown. Figure 5 Now your Logan Dining Table is ready to use. Figure 6...
  • Page 7 Page 6 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
