INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch;
do not use any phone in your building.
•
Leave the building immediately.
•
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
•
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
WARNING
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk
individuals.
NOTE: Barrier required, but may be sold separately.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
WARNING
HOT GLASS
WILL
CAUSE BURNS.
DO NOT TOUCH
GLASS
UNTIL COOLED.
NEVER
ALLOW CHILDREN
TO TOUCH GLASS.
DIRECT - VENT ZERO
CLEARANCE GAS FIREPLACE
HEATER MODELS:
MILLIVOLT
STANDING PILOT
DVP(42,48)
FP3(0,1,2,3)(N,P)-4
INTERMITTENT
PILOT
DVP(42,48)
FP7(0,1,2,3)(N,P)-5
WARNING
If not installed, operated and maintained in
accordance with the manufacturer's instruc-
tions, this product could expose you to sub-
stances in fuel or from fuel combustion which
can cause death or serious illness.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
state or local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
REMOTE
RF
DVP(42,48)FP9(1,3)
(N,P)-6
GAS-FIRED
UL FILE NO. MH30033
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVP48FP30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Empire Comfort Systems DVP48FP30

Summary of Contents for Empire Comfort Systems DVP48FP30

  • Page 1 INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL DIRECT - VENT ZERO INSTALLER: Leave this manual with the appliance. CLEARANCE GAS FIREPLACE CONSUMER: HEATER MODELS: Retain this manual for future reference. MILLIVOLT REMOTE STANDING PILOT WARNING DVP(42,48) DVP(42,48)FP9(1,3) FP3(0,1,2,3)(N,P)-4 (N,P)-6 FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly INTERMITTENT GAS-FIRED...
