CHIEF FHP18-110 Installation Instructions Manual

I N S T A L L A T I O N
Small Flat Panel Ceiling Mount
with Adjustable Column (FHP18-110)
The FHP is a sleek, Centris™ mounting system designed for all
VESA® 75mm/100mm compliant displays. The mount includes
an adjustable column, cable management, and a variety of
screen positioning options. The all-metal mount is available in
either silver or black.
The slender column on the mount is finely finished with easy
adjustment between 12 inches and 18 inches in 1 inch incre-
ments. The snap on cable management cover, fitting snugly
against the column, conceals unsightly cabling.
The mount rotates 360 degrees, allowing portrait or landscape
mounting of your display. The friction-adjustable pivot points
include 15 degrees of up and down tilt for customized move-
ment.
BEFORE YOU BEGIN
• Caution: To prevent damage to the FHP, which could affect or void the Factory warranty, and to the equip-
ment that will be attached to it, thoroughly study all instructions and illustrations before you begin the
installation. Pay particular attention to the "Important Warnings and Precautions" on Page 1.
• The maximum weight to be installed on the FHP ceiling mount is 40 pounds (18.1 Kg)
• The FHP ceiling mount is designed to be installed using supporting framework. The structure to which the FHP
ceiling mount is anchored must be capable of supporting five times the total weight of the mount and all attached
equipment.
• If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480.
