Part names and functions
Front
①
④
Back
⑨
Bottom
⑭
② ③
⑤
⑥
⑦
⑧
⑩ ⑪
⑫
⑬
① Top control and Indicators
② Zoom ring
③ Lamp cover
④ Filter
⑤ Remote control receiver
⑥ Projector lens
⑦ Air intake vent
⑧ Focus ring
⑨ AC cord connector
⑩ Terminals
⑪ Anti-thief slot
⑫ Speaker
⑬ Adjustable foot
⑭
Exhaust vent
Caution
Hot air is exhausted from the exhaust vent. Do
not put heat-sensitive objects near this side.
