HMT1
INSTRUCTION MANUAL
Para Español ver página 14
Want to watch a
video that shows
how easy this DIY
project will be?
Watch it now at:
SANUS.com/2939
WE'RE HERE TO HELP
Recommended placement
Check it out at:
SANUS.com/2933
Get it right the
first time.
HeightFinder
™
shows you
where to drill.
Call us at:
888-384-1115
Our US-based
install experts
are standing
by to help.
Or, chat at:
SANUS.com/chatSH
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sanus HMT1
Summary of Contents for Sanus HMT1
- Page 1 HMT1 INSTRUCTION MANUAL Para Español ver página 14 WE’RE HERE TO HELP Want to watch a Get it right the Our US-based Recommended placement video that shows first time. install experts how easy this DIY HeightFinder are standing ™ project will be? shows you by to help.
- Page 2 Does your TV No — Perfect! (including accessories) 80 lbs. weigh more than Yes — This mount is NOT compatible. Visit MountFinder.Sanus.com or call (36.3 kg) 80 lbs. (36.3 kg)? 888-384-1115 to find a compatible mount. What is your Drywall with...
- Page 3 Dimensions TV INTERFACE 15.75in 400mm 7.87in 200mm 7.87in 15.75in 200mm 400mm 0.35in 8.8mm WALL PLATE FRONT VIEW - LATERAL SHIFT SIDE VIEW - TILT 5deg 10deg TILT 15.42in DOWN 391.7mm 4.75in 120.7mm 3.91in 99.4mm 2.93in 74.4mm 0.33in 8.4mm FULLY ASSEMBLED MOUNT SIDE VIEW 17.78in 2.04in...
-
Page 4: Parts And Hardware
Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used. - Page 5 M6 x 35mm M8 x 50mm M8 x 35mm Parts and Hardware for STEP 2 5/16 x 2¾ in. 5/16 x 2 ¾ in. Lag Bolt M8 x 40mm (qty. 2) M4/M5 M6/M8 2.5mm .695 x .350 x .075 in. Washer (qty.
-
Page 6: Step 1 Attach Brackets To Tv
STEP 1 Attach Brackets to TV 1-1 Select TV Screw Diameter 1-2 Select TV Screw Length If your TV included inset If your TV has a flat back AND you want your TV closer to spacers or wall mount adapters, Only one size fits your TV. - Page 7 1-3 Attach TV Brackets Ensure that your brackets are level on the back of the TV. Standard configurations are shown. For special applications, or if you are unsure about your hardware selection, contact Customer Service. Flat Back Round Back / Extra Space Spacer Options...
- Page 8 STEP 2A Attach Wall Plate to Wall Wood Stud Option CAUTION: Avoid potential personal injuries and property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 11/2 x 31/2 in. (38 x 89 mm) Locate your stud.
- Page 9 Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit. Remove wall plate template IMPORTANT: Be sure to drill into the center of the stud. IMPORTANT: Pilot holes must be drilled to a depth of 3 in. (75 mm). Install wall plate using two lag bolts and two washers...
- Page 10 STEP 2B Attach Wall Plate to Wall Solid Concrete or Concrete Block Option CAUTION: Avoid potential personal injuries and property damage! Concrete Installation Kit CMK1 is not included ● Mount the wall plate directly onto the concrete surface (see page 5) Contact Customer Service at 888-384-1115 to inquire about the additional ●...
- Page 11 Remove the wall plate template and insert three (3) anchors (Fischer UX 10 x 60R - included in the Concrete Installation Kit*). CAUTION: Be sure the anchors are seated flush with the concrete surface. Install wall plate using three (3) lag bolts and three (3) washers (use only the lag bolts and washers from the Concrete Installation Kit*).
-
Page 12: Step 3 Attach Tv To Wall Plate
STEP 3 Attach TV to Wall Plate HEAVY! You may need assistance with this step. IMPORTANT: You will hear an audible click when the TV bracket is securely fastened to the wall plate. - Page 13 Adjustments TILT LEVEL REMOVING THE TV Your TV should adjust easily when moved, then If needed, tighten one of the screws on the top Pull down on the latches and lift stay in place. of the TV bracket to level the TV. the TV up and out away from the wall plate.
- Page 14 ¿Su televisor pesa No — ¡Perfecto! más de 36.3 kg 36.3 kg (80 lb), incluidos Sí — Este soporte NO es compatible. Visite MountFinder.Sanus.com o llame al los accesorios? (80 lbs.) 888-384-1115 para encontrar un soporte compatible. ¿De qué está...
- Page 15 ESPAÑOL Dimensiones Ver página 3 Piezas y elementos de sujeción suministrados Ver página 4 ADVERTENCIA: Este producto contiene piezas pequeñas que, si fuesen tragadas, podrían producir asfixia. Antes de iniciar el ensamblaje, compruebe que todas las piezas estén incluidas y en buenas condiciones. Si faltan piezas o alguna está dañada, no devuelva el artículo al distribuidor;...
- Page 16 ESPAÑOL PASO 2A Fijar la placa mural a la pared - Opción para montantes de madera Ver página 8 PRECAUCIÓN: Evite posibles lesiones personales y daños materiales. ● El yeso que recubre la pared no debe exceder los 16 mm (5/8 pulgada). ●...
- Page 17 ESPAÑOL PASO 2B Fijar la placa mural a la pared - Opción para hormigón sólido o bloques de cemento Ver página 10 PRECAUCIÓN: Evite posibles lesiones personales y daños materiales. ● Instale la placa mural directamente sobre la superficie de hormigón. El Kit de instalación en hormigón CMK1 no ●...
- Page 18 ESPAÑOL PASO 3 Instalar el televisor en la pared Ver página 12 ¡ELEMENTO PESADO! Es posible que necesite ayuda IMPORTANTE: Oirá un clic cuando la placa de sujeción del televisor esté bien sujeta a la placa mural. en este paso. Ajustes Ver página 13 AJUSTE DE LA INCLINACIÓN: Afloje la perilla...
- Page 19 ESPAÑOL...
- Page 20 ©2020 Legrand AV Inc. All rights reserved. Sanus is a division of Legrand. SANUS and the SANUS Home logo are registered trademarks. Legrand AV Inc. • 6436 City West Parkway • Eden Prairie, MN 55344 USA...
