INSTALLATION*
Wa l l M o u n t f o r V 4 H o u s i n g
1.
Verify all parts are in
the box.
4
4.
Attach the camera's
Surface Mount Plate to
the Wall Mount.
1 1
All manuals and user guides at all-guides.com
1
2.
Run cables into the
mount.
5.
Connect all cables and
snap the camera
module onto the base.
2
5
3.
Use the mounting template to
make pilot holes. Use the dry
wall anchors and wood screws
to attach the assembly to the
wall.
6
6.
Adjust the camera and
secure the cover dome
over the camera
.
module
3
