WEBVIEWER*
S e t u p > V i d e o & A u d i o > P r i v a c y Z o n e
T h e M E G A P I X ® c a m e r a o f f e r s u p t o 3 0 p r i v a c y z o n e s e t t i n g s .
To set Privacy Zones:
1. Change Mode to On. Click Apply. By default, all 30 privacy zones will be displayed.
2. Select the color of the zone and transparency of the color from the drop down list. Click Apply.
3. Select the zones you want to view and/or modify. Use the Show All button to display all 30 privacy
zones, or Hide All to deselect them and select only a single privacy zone. Click Apply.
4. Set the zone's size and location, using the grid lines. Under Local Settings, select the zone you want
to modify, then select the position:
- Horizontal Position: 0~57
- Vertical Position: 0~31
- Width: 0~60
- Height: 0~34
5. Click Apply after each modification to
verify the size and position match your
requirements.
3 3
