Removal and Replacement Procedures

5.22 System Board

System boards (do not contain memory)
for use only with Evo Notebook N1020v models and Presario
1500 models with config. codes beginning with "L"
for use only with Evo Notebook N1000v models and Presario
1500 models with config. codes beginning with "K"
✎
When replacing the system board, ensure that the following
components are removed from the old system board and installed
on the new system board:
■
Memory expansion boards (Section 5.5)
■
Mini PCI communications board (Section 5.6)
■
Disk cell RTC battery (Section 5.7)
■
Processor (Section 5.12)
■
Modem cable (Section 5.23)
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a. LED cover (Section 5.9)
b. Keyboard (Section 5.10)
c. Heat spreader (Section 5.11)
d. Display (Section 5.13)
e. Palm rest (Section 5.14)
f.
g. Speaker assembly (Section 5.19)
5–56
System Board
Spare Part Number Information
Charger board and shield (Section 5.18)
Maintenance and Service Guide
311282-001
285515-001
