HP Compaq Presario,Presario 5526 Supplementary Manual

System Boards
System Board, P586, w/ MPEG Down*
System Board, P586, w/o MPEG Down**
* 5522, 5526, 5528, 5536
Jumper Settings (Assembly 004794, 004797)
Jumper Function
P1 CMOS Clear
P2 CPU Clock
Multiplier
P3 Bus Speed Select
Memory SIMMs
Video Memory
Microprocessor
P586/75 *
P586/90 **
* 5522, 5524, 5526, 5528
Miscellaneous Internal
Monitor Assembly, NA, POL*
Monitor Assembly, S/H
Monitor Assembly, N/H, CE
MPEG Controller
WaveTable Controller
Speaker Assembly
Logo Kit **
Backplane
* POL = Polished Glass.
Hard Drives
630 MB
840 MB
1.05 GB
*
"Hard Drive Select" cable required.
CD-ROM Drives
CD-ROM, IDE, 4 speed
3-98
Presario 5500
Assembly
004797-101
004794-101
** 5524, 5530, 5534
Pins Description
1-2 (default) Secure CMOS Power
Open Remove jumper for 10 seconds.
Reinstall to clear CMOS
A1-A2 1.5x
B1-B2
A2-A3 2.0x
B1-B2
A2-A3 2.5x
B2-B3
A1-A2 3.0x
B2-B3
1-2 50 MHz CPU Ext. Bus Freq.
2-3 40 MHz CPU Ext. Bus Freq.
3-4 60 MHz CPU Ext. Bus Freq.
4-5 66 MHz CPU Ext. Bus Freq.
** 5530, 5534, 5536
Assembly
004215-001
** Order when the monitor is replaced.
Cable Select*
Yes
Yes
Yes
Assembly
172854-001
Spare Part
214249-001
214107-001
Spare Part
213859-001
Spare Part
172760-003
172760-002
Spare Part
214137-001
214137-003
214137-004
213857-001
213858-001
214345-001
214338-001
214109-001
Spare Part
214209-001
214211-001
214213-001
Spare Part
172864-301
Volume Two
