Outer Access Casing; Replacing The Ac Power Fuse - Compaq Portable II Maintenance And Service Manual

Chapter 7.3 Outer Access Casing
To remove the outer access casing from the computer, complete the following
steps:
1. Complete the preparation procedure (see Section 7.1).
2. Place the computer keyboard side down on a level work surface.
the AC power access panel and the peripheral connector access panels.
Using a Torx screwdriver, remove the mounting screws from the AC power
and peripheral connector access areas (Figures 7-6 and 7-7).
Slide open
