Summary of Contents for ILVE ILD703G5
- Page 1 ILD703G5, ILD604G4, ILD786G5, ILD906G5, ILD914G5...
- Page 2 OPEN 24 LINE SHOP...
-
Page 3: Table Of Contents
Dear customer, Congratulations on your purchase of a ILVE induction ceramic hob. In order to make the best use of your appliance, please carefully read the following use and care manual and keep it for later reference. SUMMARY SAFETY ............................4 ...................... -
Page 4: Safety
SAFETY Precautions before using • Unpack all the materials. • The installation and connection of the appliance must be done by approved and qualified specialists. The manufacturer cannot be responsible for damage caused by installation or connection errors. • When used, the appliance must be correctly installed in a kitchen unit and an adapted and approved work surface. -
Page 5: Precautions Not To Damage The Appliance
Precautions not to damage the appliance • Raw pan bottoms or damaged saucepans (not enamelled cast iron pots) may damage ceramic glass. • Sand or other abrasive materials may damage ceramic glass. • Avoid dropping objects, even little ones, on the vitroceramic. •... -
Page 6: Description Of The Appliance
Power Power* Power* detection zone Power* Left Ø260 mm 2600 W 3300 W 5500 W 120 mm ILD703G5 7400 W Centre 220x180 mm 2100 W 2600 W 3700 W 100 mm Right 220x180 mm 2100 W 2600 W 3700 W... -
Page 7: Use Of The Appliance
USE OF THE APPLIANCE Sensitive touch Your ceramic hob is equipped with electronic controls with sensitive touch keys. When your finger presses the key, the corresponding command is activated. This activation is validated by a control light, a letter or a number in the display and/or a “beep” sound. In the case of a general use press only one key at a time. -
Page 8: Power Selection Zone "Slider" And Timer Setting Zone
Power selection zone “SLIDER” and timer setting zone To select the power with the slider, slide your finger on the “SLIDER” zone. You can directly access if you put your finger directly on the chosen level. Power selection zone “SLIDER” and timer setting zone “SLIDER“... -
Page 9: Residual Heat Indication
Residual heat indication After the heating zone is turned off, or the complete stop of the hob, the heating zones are still hot and indicates [ H ] on the display. The symbol [ H ] disappears when the heating zones may be touched without danger. When the residual heat indicators are on, don’t touch the heating zones and don’t put any heat sensitive object on them. -
Page 10: Automatic Cooking
• To stop the cooking time: Action Control panel Display Select the Timer press simultaneously key [ - ] and [ + ] Timer display on from the timer until the desired display is on Stop the time press key [ - ] from the timer [ 000 ] If several timers are activated, repeat the process. -
Page 11: Recall Function
Recall Function After switching off the hob [ ], it is possible to recall the last settings. • cooking stages of all cooking zones (Booster) • minutes and seconds of programmed cooking zone-related timers • Keep warm function The recall procedure is following: •... -
Page 12: Cooking Advice
COOKING ADVICE Pan quality Accepted materials : steel, enamelled steel, cast iron, ferromagnetic stainless-steel, aluminium with ferromagnetic bottom. Not accepted materials : aluminium and stainless-steel without ferromagnetic bottom, copper, brass, glass, ceramic, porcelain. The manufacturers specify if their products are compatible induction. To check if pans are compatible : •... -
Page 13: Examples Of Cooking Power Setting
Examples of cooking power setting (the values below are indicative) 1 to 2 Melting Sauces, butter, chocolate, gelatine Reheating Dishes prepared beforehand 2 to 3 Simmering Rice, pudding, sugar syrup Defrosting Dried vegetables, fish, frozen products 3 to 4 Steam Vegetables, fish, meat 4 to 5 Water... -
Page 14: Environment Preservation
One or all cooking zone cut-off : • The safety system has actioned. • You forgot to cut-off the cooking zone for a long period of time. • One or more sensitive keys are covered. • The pan is empty and its bottom overheated. •... -
Page 15: Installation Instructions
ILD604G5 560 x 490 mm ILD703G5 • Ensure that there is a distance of 50 mm between the hob and the wall or sides. • The hobs are classified as “Y” class for heat protection. Ideally the hob should be installed with plenty of space on either side. -
Page 16: Electrical Connection
The connection box is located underneath at the back of the hob casing. To open the cover, use a medium screwdriver. Place it in the slits and open the cover. CONNECTION OF THE HOB FOR ILD914G5 , ILD604G5 AND ILD703G5 Mains... - Page 17 CONNECTION OF THE HOB FOR ILD906G5 AND ILD786G5 Mains Connection Cable diameter Cable Protection calibre H 05 VV - F 230V~ 50/60Hz 1 Phase + N 3 x 4 mm² 40 A * H 05 RR - F H 05 VV - F 400V~ 50/60Hz 2 Phases + N 4 x 2.5 mm²...
- Page 18 Warranty Card Eurolinx Pty Limited A.B.N. 50 001 473 347 trading as ILVE (“ILVE”) Post: P: 1300 856 411 WARRANTY REGISTRATION PRIVACY WARRANTY ILVE Operating Manual...
- Page 19 Warranty Card ALL SERVICE CALLS MUST BE BOOKED THROUGH THE ILVE SERVICE AND WARRANTY DEPARTMENT ON 1300 856 411 Warranty Card tear off ILVE Operating Manual...
- Page 20 18157/0 18157/1...
