- Page 1 INSTRUCTION MANUAL FOR INDUCTION HOB MODEL: ILD88B...
- Page 2 OPEN 24 ILVE ACCESSORIES ONLINE SHOP...
-
Page 3: Table Of Contents
Dear customer, Congratulations on your purchase of a ILVE induction ceramic hob. In order to make the best use of your appliance, please carefully read the following use and care manual and keep it for later reference. SUMMARY SAFETY ............................4 ...................... -
Page 4: Safety
SAFETY Precautions before using Unpack all the materials. The installation and connection of the appliance must be done by approved and qualified specialists. The manufacturer cannot be responsible for damage caused by installation or connection errors. When used, the appliance must be correctly installed in a kitchen unit and an adapted and approved work surface. -
Page 5: Precautions Not To Damage The Appliance
Precautions not to damage the appliance Raw pan bottoms or damaged saucepans (not enamelled cast iron pots) may damage ceramic glass. Sand or other abrasive materials may damage ceramic glass. Avoid dropping objects, even little ones, on the vitroceramic. Do not hit the edges of the glass with saucepans. Make sure that the ventilation of the appliance is in accordance with the manufacturer’s ... -
Page 6: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Technical characteristic Total Nominal Minimal pan Type Zones Diameter Booster Power* Power Power* detection Front left 170 mm 1100 W 1400 W 90 mm Rear left 190 mm 1400 W 2000 W 90 mm INB885B 7400 W Center 280 mm 2300 W... -
Page 7: Use Of The Appliance
USE OF THE APPLIANCE Sensitive touch Your ceramic hob is equipped with electronic controls with sensitive touch keys. When your finger presses the key, the corresponding command is activated. This activation is validated by a control light, a letter or a number in the display and/or a “beep” sound. In the case of a general use press only one key at a time. -
Page 8: Power Selection Zone "Slider" And Timer Setting Zone
Power selection zone “SLIDER” and timer setting zone First select a cooking zone by pushing on a “Zone selection” button (see p.6). The corresponding display will be highlighted as long as the zone is activated. While the zone is activated (for a few seconds), you can adjust the power, either by sliding your finger on the slider, or by direct access. -
Page 9: Residual Heat Indication
Residual heat indication After the heating zone is turned off, or the complete stop of the hob, the heating zones are still hot and indicates [ H ] on the display. The symbol [ H ] disappears when the heating zones may be touched without danger. When the residual heat indicators are on, don’t touch the heating zones and don’t put any heat ... -
Page 10: Automatic Cooking
Automatic stop at the end of the cooking time: As soon as the selected cooking time is finished the timer display blinks [ 00 ] and a sound rings. To stop the sound and the blinking, press the key [ Egg timer function : Example for 29 minutes : Action... -
Page 11: Recall Function
Recall Function After switching off the hob ], it is possible to recall the last settings. cooking stages of all cooking zones (power) minutes and seconds of programmed cooking zone-related timers Keep warm function The recall procedure is following: Press the key [ Then simultaneously press the 2 zones back in less than 6 seconds. -
Page 12: Cooking Advices
COOKING ADVICES Pan quality Adapted materials : steel, enamelled steel, cast iron, ferromagnetic stainless-steel, aluminium with ferromagnetic bottom. Not adapted materials : aluminium and stainless-steel without ferromagnetic bottom, cupper, brass, glass, ceramic, porcelain. The manufacturers specify if their products are compatible induction. To check if pans are compatibles : Put a little water in a pan placed on an induction heating zone set at level [ 9 ].This water must heat in a few seconds. -
Page 13: Examples Of Cooking Power Setting
Examples of cooking power setting (the values below are indicative) 1 to 2 Melting Sauces, butter, chocolate, gelatine Reheating Dishes prepared beforehand 2 to 3 Simmering Rice, pudding, sugar syrup Defrosting Dried vegetables, fish, frozen products 3 to 4 Steam Vegetables, fish, meat 4 to 5 Water... - Page 14 II) First step: cancel the existing configuration 1) Press the touch B and hold down 2) With your other hand, press on the touch A during 2s. Released the touch A. A “beep” sound and the half slider lights. A double "beep" means an error occurred. If so, start again from item 1).
-
Page 15: Environment Preservation
The automatic cooking system doesn’t start-up: The cooking zone is still hot [ H ]. The highest power level is set [ 9 ]. The control panel displays [ L ]: Refer to the chapter control panel locking page. The control panel displays [ U ]: Refer to the chapter “Keep warm“. -
Page 16: Installation Instructions
INSTALLATION INSTRUCTIONS The installation comes under the exclusive responsibility of service. The installer must respect the legislation and the standards enforce in his home country. How to stick the gasket: The gasket supplied with the hob avoids all infiltration of liquids in the cabinet. Installation has to be done carefully, in conformity of the following drawing. -
Page 17: Electrical Connection
ELECTRICAL CONNECTION The installation of this appliance and the connection to the electrical network should be entrusted only to an electrician following the normal regulations. Protection against the parts under tension must be ensured after the building-in. The information on connections necessary are on the stickers. Place them on the hob casing near the connection box. - Page 18 Warranty Card Eurolinx Pty Limited A.B.N. 50 001 473 347 trading as ILVE (“ILVE”) Post: P: 1300 856 411 WARRANTY REGISTRATION PRIVACY WARRANTY ILVE Operating Manual...
- Page 19 Warranty Card ALL SERVICE CALLS MUST BE BOOKED THROUGH THE ILVE SERVICE AND WARRANTY DEPARTMENT ON 1300 856 411 Warranty Card tear off ILVE Operating Manual...
