Operation Manual Model 601, 700, 701 Microwave Moisture Bale Chute System & Pre-Compression Chamber System 601, 700, 701-17-OPR – Imp&Metric 6/22...
Page 2
European Parliment and the Council of 17 May 2006 and other applicable European Directives including Directive 2004/108/EC on the Electromagnetic compatability. The application of preservatives for hay Harvest Tec system will be turned on after being installed on a farm press has been declard in conformity with the Machinery Directive.
Introduction Thank you for purchasing this 601, 700 or 701 Microwave Moisture Sensor Kit. The Microwave Moisture Sensor Kit is designed to operator through the baler’s ISOBUS system and/or an Apple iPad (not included) using the Hay App. This manual will take you through the steps of the operation of the moisture sensor. Please read this manual carefully to learn how to operate the equipment correctly.
Moisture System Setup - MWM-PCC (Pre-Compression Chamber) Only available for AGCO 2100-2200 Series Balers and CNH BB & LB Balers Select the microwave mosture sensor option Change Chamber Width Select Correct Width Change Baler OEM if necessary Choose between AGCO and CNH...
Moisture Sensor Setup (continued) Ensure Bale Chamber or PCC is Select the Update ZA button Follow direction on Configuration empty before updating ZA value Confirmation and select OK (Zero Adjustment) ZA RANGE (Zero Adjustment) Same for Chute or PCC Setup AGCO 2200 - 3000 2200 - 3000...
Chamber Width Setup – MWM Chute (continued) 1. To change the MWM-Chute width and select the grey area. 2. A scrolling menu will appear. Select the correct value to use and select Done. MWM-Chute Offset – Distance from knotter to MWM Chute Sensor 1.
The SD LOG to USB function is used to transfer information recorded to the SD card on the applicators Dual Channel Processor (DCP) to a USB. The function is intended for troubleshooting purposes with Harvest Tec. 1. Insert a blank USB drive into the USB port on the DCP and select the SD LOG to USB button as shown above.
ZA Value – MWM-PCC and MWM-Chute *Zero Adjustment is needed to calibrate the MWM sensors on the baler. You may need to repeat this process from time to time to verify the sensors are reading correctly. *Ensure Bale Chamber or PCC is empty before updating ZA Value* 1.
The power harness must be connected to the battery! The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty. IF MODIFICATIONS ARE REQUIRED CONTACT HARVEST TEC FIRST! b. This unit will not function on positive ground tractors.
700BB - Wiring Diagram – Connecting to 696BB Preservative Applicator System 1. The Baler Power/Communication Harness (006-6650LS(E)) will attach to the open port of the Tractor Harness (006-6650TM(E)) and run back to the Dual Channel Processor (006-6671LS). Connect the large plug of the Baler Power/Communication Harness (006-6650LS) to the bottom (shorter side) of the DCP.
701BB - Wiring Diagram – Connecting to 696BB Preservative Applicator System 1. The Baler Power/Communication Harness (006-6650LS(E)) will attach to the open port of the Tractor Harness (006-6650TM(E)) and run back to the Dual Channel Processor (006-6671LS). Connect the large plug of the Baler Power/Communication Harness (006-6650LS(E)) to the bottom (shorter side) of the DCP.
The power harness must be connected to the battery! The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty. IF MODIFICATIONS ARE REQUIRED CONTACT HARVEST TEC FIRST! b. This unit will not function on positive ground tractors.
700MWM - Wiring Diagram – Connecting to 696A Preservative Applicator System 1. The Baler Power/Communication Harness (006-6650LS2(E)) will attach to the open port of the Tractor Harness (006-6650TM(E)) and run back to the Dual Channel Processor (006-6671LS). Connect the large plug of the Baler Power/Communication Harness (006-6650LS(E)) to the bottom (shorter side) of the DCP.
701MWM - Wiring Diagram – Connecting to 696A Preservative Applicator System 1. The Baler Power/Communication Harness (006-6650LS2(E)) will attach to the open port of the Tractor Harness (006-6650TM(E)) and run back to the Dual Channel Processor (006-6671LS). Connect the large plug of the Baler Power/Communication Harness (006-6650LS(E)) to the bottom (shorter side) of the DCP.
No, microwave sensors are only compatible w/ 600 Series controls w/ software version dcp46227 or later. 2. Can microwave sensors function through a Harvest Tec Touch Screen Display? No, microwave sensors require an ISOBUS Interface (VT) or iPad system to set the microwave settings.
5. Short in wire between star wheels 5. Replace wire. and DCP. 6. Check hay with hand tester to 6. Contact Harvest Tec if conditions verify. persist. 1. Test bales with hand tester to Moisture readings erratic. verify that DCP has more variation than hand tester.
Pin Outs Power/Comm Harness 006-6650TM at Hitch Pin 1 Red +12V Power to BLE Pin 2 Red +12V Power to DCP Pin 3 Orange Keyed Power Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Orange Can1 Hi Pin 8 Black...
Page 20
Pin Outs (continued) 006-6650VA to 006-6650LS(E) or LS2(E) Pin 1 Red Can Power Pin 2 Black Can Ground Pin 3 Yellow HT Can Hi Pin 4 Gray Shield 3 4 5 Pin 5 Green HT Can Low Pin 6 N/A Pin 7 N/A Main Power Connector on Dual Channel Processor (DCP) Pin 1 Red...
Page 21
Pin Outs (continued) Microwave Moisture Harness 006-6650MW or 006-6650MWL Pin 1 Red Power Pin 2 N/A Not Used Pin 3 N/A Not Used Pin 4 Yellow Can H In Pin 5 Green Can L In Pin 6 Orange Can H Out Pin 7 Blue Can L Out Pin 8 Black...
Harvest Tec, LLC. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion.
