- Page 1 Operation Manual Model 602 Microwave Moisture Bale Chute System 602-17-OPR-Imp&Metric 6/22...
- Page 2 European Parliment and the Council of 17 May 2006 and other applicable European Directives including Directive 2004/108/EC on the Electromagnetic compatability. The application of preservatives for hay Harvest Tec system will be turned on after being installed on a farm press has been declard in conformity with the Machinery Directive.
-
Page 3: Table Of Contents
602A - Wiring Diagram - AGCO 2100 & 2200 Series Balers 602BB - Wiring Diagram - CNH LB & BB Balers 602J – Wiring Diagram – John Deere Balers 602 - Wiring Diagram - Non AGCO 2100 & 2200, Non-John Deere and Non-CNH LB & BB Balers Common Questions Troubleshooting... -
Page 4: Introduction
Introduction Thank you for purchasing this 601, 700 or 701 Microwave Moisture Sensor Kit. The Microwave Moisture Sensor Kit is designed to operator through the baler’s ISOBUS system and/or an Apple iPad (not included) using the Hay App. This manual will take you through the steps of the operation of the moisture sensor. Please read this manual carefully to learn how to operate the equipment correctly. - Page 5 Select the microwave mosture sensor option Select the correct chamber width Select Chute Length Change Baler OEM if Necessary Choose between AGCO, CNH, John Deere, Krone Moisture Sensor Setup (continued)
-
Page 6: Operation Instructions
Ensure Bale Chamber or PCC is Select the Update ZA button Follow direction on Configuration empty before updating ZA value Confirmation and select OK (Zero Adjustment) ZA RANGE (Zero Adjustment) Same for Chute or PCC Setup AGCO 2200 - 3000 2200 - 3000 John Deere 2200 - 3000... -
Page 7: Selecting Baler Oem - Mwm-Chute
1. To change the MWM-Chute width and select the grey area. 2. A scrolling menu will appear. Select the correct value to use and select Done. MWM-Chute Offset – Distance from knotter to MWM Chute Sensor 1. To change the MWM-Chute offset select the grey area. *Measure Distance from the center on knotter to the center of the MWM system. -
Page 8: Identify Moisture Settings
The SD LOG to USB function is used to transfer information recorded to the SD card on the applicators Dual Channel Processor (DCP) to a USB. The function is intended for troubleshooting purposes with Harvest Tec. 1. Insert a blank USB drive into the USB port on the DCP and select the SD LOG to USB button as shown above. -
Page 9: 602A - Wiring Diagram - Agco 2100 & 2200 Series Balers
The sensor type selected is indicated in the upper right corner of the run screen (above) on both Automatic and Manual Mode. MC-0 indicates starwheels, MC-1 indicates MWM Pre-Compression Chamber, MC-2 indicates MWM Bale Chamber System, MWM-3 indicates other. 602A - Wiring Diagram – AGCO 2100 & 2200 Series Balers... -
Page 10: 602Bb - Wiring Diagram - Cnh Lb & Bb Balers
1. Locate the tractor power/communication harness (006-6650TM(E)). 2. At the back of the tractor run the power leads to the battery. 3. Connect the red power wire with the 50 amp fuse to the positive side (12 volt) of the battery. a. -
Page 11: 602J - Wiring Diagram - John Deere Balers
1. Locate the tractor power/communication harness (006-6650TM(E)). 2. At the back of the tractor run the power leads to the battery. 3. Connect the red power wire with the 50 amp fuse to the positive side (12 volt) of the battery. a. -
Page 12: 602 Wiring Diagram - Non Agco 2100 & 2200, Non-John Deere And Non-Cnh Lb & Bb Balers
Keyed Power Power/Comm Harness on Baler 006-6650LS2(E) Keyed Power Extension 006-5650K Power/Comm Harness on Tractor 006-6650TM(E) *Note: (E) indication is used 602 Wiring Diagram – Non AGCO 2100 & 2200, Non-John Deere and Non-CNH LB & BB Balers for International Dealers... -
Page 13: Common Questions
1. Locate the tractor power/communication harness (006-6650TM(E)). 2. At the back of the tractor run the power leads to the battery. 3. Connect the red power wire with the 50 amp fuse to the positive side (12 volt) of the battery. a. -
Page 14: Troubleshooting
No, microwave sensors are only compatible w/ 600 Series controls w/ software version dcp46227 or later. 2. Can microwave sensors function through a Harvest Tec Touch Screen Display? No, microwave sensors require an ISOBUS Interface (VT) or iPad system to set the microwave settings. -
Page 15: Pin Outs
5. Short in wire between star wheels 5. Replace wire. and DCP. 6. Check hay with hand tester to 6. Contact Harvest Tec if conditions verify. persist. 1. Test bales with hand tester to Moisture readings erratic. verify that DCP has more variation than hand tester. - Page 16 Power/Comm Harness 006-6650TM(E) at Hitch Pin 1 Red +12V Power to BLE Pin 2 Red +12V Power to DCP Pin 3 Orange Keyed Power Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Orange Can1 Hi Pin 8 Black...
- Page 17 006-6650VA to 006-6650LS(E) or LS2(E) Pin 1 Red Can Power Pin 2 Black Can Ground Pin 3 Yellow HT Can Hi Pin 4 Gray Shield 3 4 5 Pin 5 Green HT Can Low Pin 6 N/A Pin 7 N/A Main Power Connector on Dual Channel Processor (DCP) Pin 1 Red +12V Power from tractor...
- Page 18 Microwave Moisture Harness 006-6650MW or 006-6650MWL Pin 1 Red Power Pin 2 N/A Not Used Pin 3 N/A Not Used Pin 4 Yellow Can H In Pin 5 Green Can L In Pin 6 Orange Can H Out Pin 7 Blue Can L Out Pin 8 Black Ground...
-
Page 19: Parts Breakdown
Parts Breakdown Star Wheel Moisture Sensor and Bale Rate Sensors Ref Description Part Number Qty Description Part Number Qty Block cover 006-4641B Star wheel block 006-4641A Electronic swivel 006-4642A Star wheel sensor 030-4641C Swivel insert w/ Ref # 10 Twine guard-left 001-4645 Snap ring (per side) 006-4641K Twine guard-right (prox) - Page 20 602 Control and Harnesses Ref Description Part Number Dust Plugs 006-5651PLUGS End of Bale Sensor 600 Series 006-7400 Hesston 4755, 4910 EOB Mount 001-4648H EOB Bracket CLAAS 3300 001-4648C Krone EOB Bracket 001-4648K EOB BKT Krone 12130 001-4648K2 End of Bale Sensor Bracket...
- Page 21 602A Control and Harnesses Description Part Number DCP Baler Interface Harness 006-6650VA Key Switch Wire 006-5650K End Of Bale Sensor 006-7400 Terminating Connector w green cap 006-5650Z End of Bale Sensor Bracket 001-4648 DCP Shield/Cover 001-5650X DCP Main Control LS 600 AUTO 006-6671LS DCP Baler Harness 30 FT 006-6650LS2(E)
- Page 22 602BB Controls and Harnesses Ref Description Part Number DCP Baler ISO/VT Harness 006-6650VA EOB Extension for CNH BB Series 006-7400BBEXT Key Switch Wire 006-5650K End of Bale Sensor 600 Series 006-7400 End of Bale Sensor Bracket 001-4648 Terminating Connector 600 Series w/green cap 006-5650Z DCP Shield/Cover 001-5650X DCP Main Control LS 600 AUTO...
- Page 23 602J Control and Harnesses Ref Description Part Number Dust Plugs 006-5651PLUGS End of Bale Sensor 600 Series 006-7400 End of Bale Sensor Bracket 001-4648J DCP Shield Cover 001-5650X DCP Main Control LS 600 AUTO 006-6671LS Terminating Connector (Green Cap) 006-5650Z DCP Baler Harness 30 Ft 006-6650LS2(E) DCP Tractor Harness...
- Page 24 Microwave Moisture Bale Chute System Description Part # MWM Rear Mounting Bracket 001-2601 Microwave TX Sensor 006-4641MTX End of Bale Extension Harness (20’) 006-7400MXT MWM Pre-Compression Harness 006-6650MWL Microwave RX Sensor 006-4641MRX End of Bale Bracket (Stuffer Bracket) 001-4648SS End of Bale Sensor (Stuffer Sensor) 006-7400 Power / Comm Extension Harness (25’) 006-6650FMX...
- Page 25 Optional iPad Mini Mounting Kit (030-2014MK) Description Part # Suction cup mount 001-2012SCM Ram mount 001-2012H iPad Mini spring load cradle (Mini 1,2,3) 001-2012SLC 16 gauge power wire 006-4723P Female spade connector Hardware Eye loop connector Hardware iPad Mini Charger 12V 001-2012P iPad Mini 4 case 001-2012C4...
- Page 26 Optional iPad Display Kit (030-4670DK) Description Part # Ref Description Part # Suction cup mount 001-2012SCM iPad Mini Charger 12V 001-2012P Ram mount 001-2012H iPad Mini 4 case 001-2012C4 iPad Mini spring load 001-2012SLC iPad Mini 4 006-4670IP cradle (Mini 4) 16 gauge power wire 006-4723P 4 amp fuse...
- Page 27 Harvest Tec, LLC. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion.
- Page 28 HARVEST TEC, LLC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
