- Page 1 Installation Manual Model 601BB, 700, 701 Microwave Moisture Bale Chute System & Pre-Compression Chamber System 601BB, 700, 701-17-INST- Imp&Metric 6/22...
- Page 2 European Parliment and the Council of 17 May 2006 and other applicable European Directives including Directive 2004/108/EC on the Electromagnetic compatability. The application of preservatives for hay Harvest Tec system will be turned on after being installed on a farm press has been declard in conformity with the Machinery Directive.
-
Page 3: Table Of Contents
601BB, 700, 701 Installation Manual Table of Contents PAGE Introduction System Requirements Tools Needed Installation of Moisture Sensor Kit Microwave Moisture Sensor Installation – 601BB & 700MWM Microwave Moisture Sensor Installation – 701MWM 601BB - Wiring Diagram 700BB - Wiring Diagram... -
Page 4: Introduction
Introduction Congratulations and thank you for purchasing a Harvest Tec Model 601BB, 700, 701 Microwave Moisture kit. Please read this manual carefully to ensure correct steps are taken to attach the system to the baler. This is designed to read moisture through the baler’s monitor or Apple iPad. A parts break of the system is located in the back of the manual. -
Page 5: Installation Of Moisture Sensor Kit
Microwave Sensor Installation 601BB, 700MWM Begin by opening the front shield, twine box doors, and pre- compression chamber (PCC) shield doors. Locate the mounting template in the kit, and go to the right side of the baler. Figure 1 Follow the curvature of the PCC and locate the fillet weld at the top. Index the bottom of that weld with the point at the top of the curved edge of the template (figure 2). - Page 6 Microwave Sensor Installation 600BB, 700MWM (continued) Install eight bolts 5/16”x 1” BHCS from the inside of the pre-compression chamber through the side of the PCC and the plastic filler plate (001-2600FP). Secure the top two bolts and bottom two bolts with 5/16” flanged nuts. Place a mounting bracket over each of the two bolts on the sides of the filler plate and secure with 5/16”...
- Page 7 Microwave Sensor Installation (continued) Route the rest of the harness along the steel hydraulic lines and existing wiring toward the top of the chamber. The wire from the stuffer sensor will be connected to the 4 pin connector coming off the main harness about 2’ (.6M) from the right hand sensor.
-
Page 8: Microwave Moisture Sensor Installation 701Mwm
Microwave Moisture Sensor Installation 701MWM Locate the mounting holes on the back of both the left and right side of the bale chute (figure 1). Mount the rear microwave moisture mounting brackets 001-2601 (figure 2) on the holes using two 3/8” x 3 1/2" hex bolts, nuts and lock washers located in parts bag D. -
Page 9: 601Bb - Wiring Diagram
601BB - Wiring Diagram – Connecting to Moisture Only System 1. Locate the tractor power/communication harness (006-6650TM(E)). 2. At the back of the tractor run the power leads to the battery. 3. Connect the red power wire with the 50 amp fuse to the positive side (12 volt) of the battery. -
Page 10: 700Bb - Wiring Diagram
700BB - Wiring Diagram – Connecting to 696BB Preservative Applicator System 1. The Baler Power/Communication Harness (006-6650LS2(E)) will attach to the open port of the Tractor Harness (006-6650TM) and run back to the Dual Channel Processor (006-6671LS(E)). Connect the large plug of the Baler Power/Communication Harness (006-6650LS(E)) to the bottom (shorter side) of the DCP. -
Page 11: 701Bb - Wiring Diagram
701BB - Wiring Diagram – Connecting to 696BB Preservative Applicator System 1. The Baler Power/Communication Harness (006-6650LS2(E)) will attach to the open port of the Tractor Harness (006-6650TM) and run back to the Dual Channel Processor (006-6671LS). Connect the large plug of the Baler Power/Communication Harness (006-6650LS(E)) to the bottom (shorter side) of the DCP. -
Page 12: Pin Outs
Pin Outs Power/Comm Harness 006-6650TM(E) at Hitch Pin 1 Red +12V Power to TSD Pin 2 Red +12V Power to DCP Pin 3 Orange Keyed Power Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Orange Can1 Hi Pin 8 Black... - Page 13 Pin Outs (continued) 006-6650VA to 006-6650LS(E) Pin 1 Red Can Power Pin 2 Black Can Ground Pin 3 Yellow HT Can Hi Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 N/A Pin 7 N/A 006-6650VA Harness to Baler Plug Pin A N/A Pin B Red TBC Power...
- Page 14 Pin Outs (continued) Microwave Pre-Compression Chamber Harness 006-6650MW Pin 1 Red Power Pin 2 N/A Not Used Pin 3 N/A Not Used Pin 4 Yellow Can H In Pin 5 Green Can L In Pin 6 Orange Can H Out Pin 7 Blue Can L Out Pin 8 Black...
-
Page 15: Common Questions
No, microwave sensors are only compatible w/600 Series unit running software version dcp46227 or later. 2. Can microwave sensors function through a Harvest Tec Touch Screen Display? No, microwave sensors require an ISOBUS Interface (VT) or iPad system to set the microwave settings. -
Page 16: Troubleshooting
5. Short in wire between star wheels 5. Replace wire. and DCP. 6. Check hay with hand tester to 6. Contact Harvest Tec if conditions verify. persist. 1. Test bales with hand tester to Moisture readings erratic. verify that DCP has more variation than hand tester. -
Page 17: Parts Breakdown
Microwave Moisture Pre-Compression System - 601BB & 700MWM Description Part # MWM Mounting Bracket 001-2600 Microwave TX Sensor 006-4641MTX MWM Filter Plate 006-2600FP MWM Pre-Compression Harness 006-6650MW Microwave RX Sensor 006-4641MRX End of Bale Bracket (Stuffer Bracket) 001-4648SS End of Bale Sensor (Stuffer Sensor) -
Page 18: Microwave Moisture Bale Chute System - 701Mwm
Microwave Moisture Bale Chute System – 701MWM Description Part # MWM Rear Mounting Bracket 001-2601 Microwave TX Sensor 006-4641MTX End of Bale Extension Harness (20’) 006-7400MXT MWM Pre-Compression Harness 006-6650MWL Microwave RX Sensor 006-4641MRX End of Bale Bracket (Stuffer Bracket) 001-4648SS End of Bale Sensor (Stuffer Sensor) 006-7400... -
Page 19: Warranty
Harvest Tec, LLC. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion. - Page 20 HARVEST TEC, LLC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
