- Page 1 Installation Manual Model 602A Microwave Moisture Bale Chute System AGCO 2100 & 2200 Series Balers Forage Harvester 602A-17-INST-Imp&Metric 6/22...
- Page 2 Council of 17 May 2006 and other applicable European Directives including Directive 2004/108/EC on the Electromagnetic compatability. The application of preservatives for hay Harvest Tec system will be turned on after being installed on a farm press has been declard in conformity with the Machinery Directive.
-
Page 3: Table Of Contents
602A Installation Manual Table of Contents Page Introduction System Requirements Tools Needed Installation of the Moisture Sensor 5-10 Installation of Dual Channel Processor Installation of the Star Wheels Installation of the End of Bale Sensor Installation of the Star Wheel and Bale Rate Harness... -
Page 4: Introduction
Introduction Congratulations and thank you for purchasing a Harvest Tec Model 602A Microwave Moisture kit. Please read this manual carefully to ensure correct steps are taken to attach the system to the baler. This is designed to read moisture through the baler’s monitor or Apple iPad. A parts break of the system is located in the back of the manual. -
Page 5: Installation Of The Moisture Sensor
Installation of the Dual Channel Processor Follow the instructions below to mount the Dual Channel Processor (DCP) on to your specific baler model and type. The locations shown are on the right twine box (looking at the back of the baler). Mark and drill the four 3/8 (10mm) holes and install DCP with four 5/16 x 1 bolts, locks, flats and nuts. -
Page 6: Installation Of The Star Wheels
Installation of the Star Wheels The star wheel block has a plug on one side and a wire grommet on the other side. If there is interference or problems with the star wheel wires on one side of the block, exchange the wire grommet with the plug so the wire can exit the block on the opposite side. -
Page 7: Installation Of The End Of Bale Sensor
Installation of End of Bale Sensor The end of bale sensor determines the position of the needles on the baler. When the needles cycle the sensor communicates this information to the Dual Channel Processor. This information is used for job records and will be used by the optional Bale Identification systems. -
Page 8: Installation Of The Star Wheel And Bale Rate Harness
Baler Interface Harness (006-6650VA) to that location. Reconnect Active Terminator to open port of that same harness (006-6650VA). If your baler does not have a Terminator at this location please call Harvest Tec. If your baler has the White Terminating Resistor you will need to attach the Pre 2012 AGCO Integration Harness (006-6650VAX) to the end of the Baler Interface harness (006-6650VA). -
Page 9: Microwave Sensor Installation
Microwave Sensor Installation Locate the mounting holes on the back of both the left and right side of the bale chute (figure 1). Mount the rear microwave moisture mounting brackets 001-2601 (figure 2) on the holes using two 3/8” x 3 1/2" hex bolts, nuts and lock washers located in parts bag D. - Page 10 Microwave Sensor Installation (continued) Locate the 006-7400 harness (stuffer sensor) and the L-shaped bracket (001-4648SS) from the parts bag. Attach the stuffer sensor to the bracket loosely and locate the shielding on the right hand side of the baler ahead of the stuffer. Position the stuffer sensor and L-bracket against the outside of the shield so the sensor is positioned within 3/8”...
-
Page 11: Wiring Diagram
Wiring Diagram 1. Locate the tractor power/communication harness (006-6650TM(E)). 2. At the back of the tractor run the power leads to the battery. 3. Connect the red power wire with the 50 amp fuse to the positive side (12 volt) of the battery. a. -
Page 12: Pin Outs
Pin Outs Power/Comm Harness 006-6650TM(E) at Hitch Pin 1 Red +12V Power to TSD Pin 2 Red +12V Power to DCP Pin 3 Orange Keyed Power Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Orange Can1 Hi Pin 8 Black... - Page 13 Pin Outs (continued) 006-6650VA to 006-6650LS2(E) Pin 1 Red Can Power Pin 2 Black Can Ground Pin 3 Yellow HT Can Hi Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 N/A Pin 7 N/A 006-6650VA Harness to Baler Plug Pin A N/A Pin B Red TBC Power...
- Page 14 Pin Outs (continued) Microwave Pre-Compression Chamber Harness 006-6650MWL Pin 1 Red Power Pin 2 N/A Not Used Pin 3 N/A Not Used Pin 4 Yellow Can H In Pin 5 Green Can L In Pin 6 Orange Can H Out Pin 7 Blue Can L Out Pin 8 Black...
-
Page 15: Common Questions
No, microwave sensors are only compatible w/600 Series unit running software version dcp46227 or later. 2. Can microwave sensors function through a Harvest Tec Touch Screen Display? No, microwave sensors require an ISOBUS Interface (VT) or iPad system to set the microwave settings. -
Page 16: Troubleshooting
5. Short in wire between star wheels 5. Replace wire. and DCP. 6. Check hay with hand tester to 6. Contact Harvest Tec if conditions verify. persist. 1. Test bales with hand tester to Moisture readings erratic. verify that DCP has more variation than hand tester. -
Page 17: Parts Breakdown
Parts Breakdown Star Wheel Moisture Sensor and Bale Rate Sensors Description Part# Description Part# Block cover 006-4641B Star wheel block 006-4641A Electronic swivel 006-4642A Star wheel sensor 030-4641C Swivel insert w/ Ref # 10 Twine guard-left for AGCO 001-4645H Snap ring (per side) 006-4641K Twine guard-right for 001-4644H... -
Page 18: 602A Control Boxes And Wiring Harnesses
602A Control and Harnesses Ref Description Part Number End Of Bale Sensor 006-7400 Terminating Connector w green cap 006-5650Z End of Bale Sensor Bracket 001-4648 DCP Shield/Cover 001-5650X DCP Main Control LS 600 AUTO 006-6671LS DCP Baler Harness 30 FT... -
Page 19: Microwave Moisture Bale Chute System
Microwave Moisture Bale Chute System Description Part # MWM Rear Mounting Bracket 001-2601 Microwave TX Sensor 006-4641MTX End of Bale Extension Harness (20’) 006-7400MXT MWM Pre-Compression Harness 006-6650MWL Microwave RX Sensor 006-4641MRX End of Bale Bracket (Stuffer Bracket) 001-4648SS End of Bale Sensor (Stuffer Sensor) 006-7400 Power / Comm Extension Harness (25’) 006-6650FMX... -
Page 20: Optional Ipad Mini Mounting Kit (030-2012Mk)
Optional iPad Mini Mounting Kit (030-2014MK) Description Part # Suction cup mount 001-2012SCM Ram mount 001-2012H iPad Mini spring load cradle (Mini 4) 001-2012SLC 16 gauge power wire 006-4723P Female spade connector Hardware Eye loop connector Hardware iPad Mini Charger 12V 001-2012P iPad Mini 4 case 001-2012C4... -
Page 21: Optional Ipad Display Kit (030-2370Dk)
Optional iPad Display Kit (030-4670DK) Description Part # Ref Description Part # Suction cup mount 001-2012SCM iPad Mini Charger 12V 001-2012P Ram mount 001-2012H iPad Mini 4 case 001-2012C4 iPad Mini spring load 001-2012SLC iPad Mini 4 006-4670IP cradle (Mini 4) 16 gauge power wire 006-4723P 4 amp fuse... -
Page 22: Notes
Notes... -
Page 23: Warranty Statement
Harvest Tec, LLC. . within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion. - Page 24 HARVEST TEC, LLC. . P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
