Using the Monitor
Connecting the Air Hose
Insert the air connector plug into the air
socket firmly.
Connecting the AC Adapter
Insert the AC adapter plug into
the DC jack. Then, insert the
AC adapter into an electrical outlet.
The AC adapter part # TB-233,
is sold separately.
• Use the specified AC adapter.
(See Technical Data)
• When disconnecting the AC adapter from the electrical outlet, grasp
the body of the AC adapter plug and gently pull the AC adapter out
of the outlet.
• When disconnecting the AC adapter plug from the blood pressure
monitor, grasp the monitor and gently pull the AC adapter plug out of
the monitor.
Air Hose
Air Connector Plug
Air Socket
AC adapter Plug
DC Jack
E-10
