The Model G1021X2 is the same as the Model G1021X, except it has a different spiral cutterhead and a
pedestal-mounted switch. Besides the data sheet, circuit requirements, parts, and wiring diagram in this
insert, the content in the Model G1021X owner's manual is the same for both machines. Before operating
your new machine, you MUST read and understand this insert and the entire Model G1021X manual to
reduce the risk of injury from improper use or setup.
If you have any further questions about this manual insert or the differences between the Model G1021X2
and the Model G1021X, contact our Technical Support at (570) 546-9663 or email techsupport@grizzly.
com.
Machine Inventory (See G1021X
Manual, Page 12)
The following machine inventory has been updat-
ed:
Box 1 (Figure 3)
A. Planer Unit (not shown) .............................. 1
B. Extension Tables ........................................ 2
C. Dust Port .................................................... 1
D. Handwheel ................................................. 1
Hardware and Tools
Hex Bolts M8-1.25 x 25 (Ext. Tables) ............... 6
Set Screws M8-1.25 x 12 (Ext. Tables) ............ 6
Hex Nut M10-1.25 (Handwheel) ........................ 1
Flat Washer 10mm (Handwheel) ...................... 1
Direction Label (Hi-Lo) (Handwheel) ................. 1
Key 4 x 4 x 10 (Handwheel) .............................. 1
Handwheel Handle (Handwheel) ....................... 1
Flange Bolts M6-1 x 12 (Dust Port) ................. 6
Indexable Carbide Inserts 15 x 15 x 2.5 ......... 10
Flat Head Torx Screws #10-32 x
Hex Wrenches 3, 4, 5, 6mm ....................... 1 ea.
Wrenches 8/10, 12/14mm ............................1 ea.
Torx Bits T-25 .................................................... 5
Torx T-Handle Wrench
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
/
" ............... 10
1
2
/
" ................................ 1
1
4
COPYRIGHT © JANUARY, 2008 BY GRIZZLY INDUSTRIAL, INC.
#BL10369 PRINTED IN CHINA
MODEL G1021X2
15" EXTREME SERIES PLANER
w/SPIRAL CUTTERHEAD
MANUAL INSERT
Extension Tables (See G1021 Manual,
Page 14)
The following components and hardware have
changed. Otherwise, installation of the exten-
sion tables is identical to the instructions in the
G1021X manual.
Components and Hardware Needed:
Set Screws M8-1.25 x 12 .................................. 6
Dust Port (See G1021X Manual,
Qty
Page 15)
The following components and hardware have
changed.
Components and Hardware Needed:
Flange Bolts M6-1 x 12 ..................................... 6
To install the dust hood:
1.
Secure the dust port to the planer upper
cover and the head casting with the flange
bolts.
Qty
Qty
