- Page 1 Installation Guide Integrated Refrigerator / Freezer 7 SERIES VBI7360 / CVBI7360 FBI7360 / CFBI7360 MVBI7360 / CMVBI7360 MFBI7360 / CMFBI7360...
-
Page 2: Table Of Contents
Table of Contents Warnings and Important Information _______________________________________________________ 3 Professional Bottom-Freezer Dimensions _______________________________________________________________________ 5 Specifi cations ______________________________________________________________________ 6 Cutout Dimensions__________________________________________________________________ 7 Anti-Tip Dimensions (36”) ____________________________________________________________ 9 General Information Electrical Requirements _____________________________________________________________ 10 Water Requirements ________________________________________________________________ 11 Unpacking & Moving ___________________________________________________________________ 12 Installation Door/Drawer Panel Adjustments ______________________________________________________ 12 Custom Front Panel Dimensions ______________________________________________________ 13... -
Page 3: Warnings And Important Information
IMPORTANT – Please Read and Follow! • Make sure that incoming voltage is the Your safety and the safety of others is very same as unit rating. An electric rating important. plate specifying voltage, frequency, We have provided many important safety wattage, amperage, and phase is messages in this manual and on your appliance. - Page 4 • The required use of a GFI is normally related to the location of a receptacle with respect to any signifi cant sources of water or moisture. • Viking Range, LLC will warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below.
-
Page 5: Dimensions
83-15/16” (213.2 cm) 12-1/8” (30.8 cm) 17-1/16” (43.3 cm) 4-1/16” (10.3 cm) Model Dimension A Dimension B* 27-3/8" (69.5 cm) 24-3/4" (62.9 cm) VBI7360/CVBI7360 24" (61.0 cm) FBI7360/CFBI7360 MVBI7360/CMVBI7360 27" (68.5 cm) 24-3/4" (62.9 cm) *To outside of door panel... -
Page 6: Specifi Cations
19.95 cu. ft. (565.9 liters) Approximate shipping weight 565 lbs. (254.3 kg) 36” Integrated Refrigerator/Freezer w/Custom Panels Description FBI7360 / CFBI7360 Overall width 36" (91.4 cm) Overall height (from bottom) 83-15/16" (213.2 cm) min to 84-3/4" (215.7 cm) max Overall depth from rear To front edge kickplate: 22-1/2”... -
Page 7: Cutout Dimensions
Cutout Dimensions (Bottom-Freezer) Electric Outlet Location 1 5 - 1 / 2 ” ( 3 9 . 4 c 4 - 1 / 4 ” ( 1 0 . 8 c l e v e l i n d i m e n s i o n 8 4 ”... - Page 8 Tipping Radius 9-1/2" (24.1 cm) 37-1/4" (94.6 cm) 39-5/16" (99.8 cm) 1050 127-3/16" (323.1 cm) 36" (94.4 cm) 91-7/16" (232.3 cm) 83-15/16" (213.2 cm) 111-3/16" (323.1 cm) 24-5/8" (62.5 cm) 87-3/4" (222.9 cm) 83-15/16" (213.2 cm) 17-1/4" (43.8 cm)
-
Page 9: Anti-Tip Dimensions (36")
Anti-Tip Dimensions (Bottom-Freezer) WARNING TIP OVER HAZARD Appliance is top heavy and tips easily when not completely installed. To avoid a hazard due to instability of the appliance, it must be installed according to the instructions including the anti-tip bracket Anti-tip Bracket There are 12 hole locations on the anti-tip bracket. -
Page 10: General Information
General Information Area Requirements If codes permit a separate grounding wire Verify the following: to be used, it is recommended that a qualifi ed • Unit can fi t into residence and can be electrician determine that the grounding path is moved around corners and through adequate. - Page 11 Use two or more people to valve behind the unit. move and install appliance. Failure to do so can result • The installation of Viking Range, LLC units with in death or serious injury. as long a reverse osmosis system is acceptable...
-
Page 12: Unpacking & Moving
Moving Unit Remove shipping brackets from skid by removing four Slip appliance dolly between unit and skid. bolts (two on each side) with a 1/2” (1.3 cm) deep-well Remove unit from skid. Note: Use excess packaging socket wench and a pair of pliers. Note: Tilting unit is not to protect decorative trim;... -
Page 13: Custom Front Panel Dimensions
Optional Custom Front Panels - Dimensions Note: Each panel overlay must be dry, solid, straight one-piece panels. The use of multiple panel pieces to achieve the dimensions is not recommended. Maximum panel weight: Refrigerator door panel - 39 lbs (17.6 kg) Top Freezer drawer panel - 10 lbs (4.5 kg) Bottom Freezer drawer panel - 13 lbs (5.9 kg) Custom Panel - hole locations... -
Page 14: Custom Front Panel Install
Optional Custom Front Panels - Install In order to access the mounting holes, unsnap panel trim on both sides of all three doors. Panel trim Mounting screws go thru "C" channel bracket on the side of the door and then thru the back of custom panel (2 per panel) -
Page 15: Water Line Installation
Water Line Installation WARNING TIP OVER HAZARD Appliance is top heavy and tips easily when not completely installed. To avoid a hazard due to instability of the appliance, it must be installed according to the instructions including the anti-tip bracket Ensure you have approximately 6 ft. - Page 16 Water Line Installation With the refrigerator in line with the cut- out, but outside of the cabinetry, insert the copper tubing through the indicated hole. Push the copper tubing through the machine compartment until it comes out the front side of the refrigerator. Roll the refrigerator into place in the cabinet cut-out.
-
Page 17: Leveling Unit
Leveling Unit Once the unit is in position, height adjustment can be made from the front. Remove panel just below the water fi lter. Using a 5/16" hex drive, turn clockwise to raise the unit or counterclockwise to lower. Use the lowest torque setting when using a power drill. -
Page 18: Flush Mount Side Trim
Flush Mount Side Trim After the unit has been placed in the cutout, leveled and all connections completed, the unit will need to be fastened to the cabinetry. Open the door and remove the drawers. Using the fl at wood screws, fasten the unit to the cabinetry on both sides. -
Page 19: Door Stop Adjustment
Door Stop Adjustment Your refrigerator is factory set at a 90 degree opening. The 90 degree door stop opening is shown in the illustration below with the long end of the door stop facing away from the door. To change to 105 door stop, locate the door stop on top of the door hinge. - Page 20 Water Filter System Specifi cation and Performance Data Sheet This system has been tested according to NSF/ANSI 42/53 for reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration of less than or equal to the permissible limit for water leaving the system, as specifi ed in NSF/ANSI 42/53.* (100% safety factors built-in for unmetered usage for health claims only.) NSF Specifi ed Chal-...
-
Page 21: System Specifi Cations And Data
Performance Checklist —Verify cabinet size. — Verify electrical supply and water supply (if applicable). — Install anti-tip device(s) and verify unit is secure. — Position unit in cutout, level at desired height and secure unit. —Plug-in unit and verify operation. —Connect water supply (if applicable). -
Page 22: Service & Registration
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-(845-4641), or write to: VIKING RANGE, LLC... - Page 24 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com 055156-000F EN (033120)
