INSTRUCTION MANUAL
RK6040
60-ton, Single-acting,
Die-type Crimping Tool
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
999 4670.0 REV 1
© 2002 Greenlee Textron
4/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fairmont RK6040 and is the answer not in the manual?

Questions and answers

Related Manuals for Greenlee Fairmont RK6040

Summary of Contents for Greenlee Fairmont RK6040

  • Page 1 INSTRUCTION MANUAL RK6040 60-ton, Single-acting, Die-type Crimping Tool Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 999 4670.0 REV 1 © 2002 Greenlee Textron 4/02...

  • Page 2: Table Of Contents

    Replacement manuals are available upon request at no charge. All specifications are nominal and may change as design improve- ments occur. Greenlee Textron shall not be liable for damages resulting from misapplication or misuse of its products. Dynapress is a registered trademark of Greenlee Textron.

  • Page 3: Important Safety Information

    RK6040 60-ton, Single-acting, Die-type Crimping Tool IMPORTANT SAFETY INFORMATION SAFETY ALERT SYMBOL This symbol is used to call your attention to hazards or unsafe practices which could result in an injury or property damage. The signal word, defined below, indicates the severity of the hazard.
  • Page 4 RK6040 60-ton, Single-acting, Die-type Crimping Tool IMPORTANT SAFETY INSTRUCTIONS Electrical shock hazard: This tool is not insulated. When using this unit near energized electrical lines, use only certified non-conductive hoses and proper personal protective equipment. Failure to observe this warning can result in severe injury or death.

  • Page 5: Identification

    RK6040 60-ton, Single-acting, Die-type Crimping Tool Identification—RK6040 Specifications Weight ... 20.2 kg (45 lb) Width ...152.5 mm (6") Height ...431.8 mm (17") Stroke (with dies) ... 37.8 mm (1.5") Die Type ... Burndy “L” type and Alcoa 6000 series Crimp Force ... 530 kN (60 tons) Power Source Required ...

  • Page 6: Setup

    RK6040 60-ton, Single-acting, Die-type Crimping Tool Setup Do not use this crimping tool with any hydraulic hoses or other hydraulic components rated at less than 700 bar (10,000 psi). Failure to observe this warning will result in severe injury or death.

  • Page 7: Operation

    RK6040 60-ton, Single-acting, Die-type Crimping Tool Operation Electrical shock hazard: This tool is not insulated. When using this unit near energized electrical lines, use only certified non-conductive hoses and proper personal protective equipment. Failure to observe this warning can result in severe injury or death.

  • Page 8: Illustration And Parts List

    RK6040 60-ton, Single-acting, Die-type Crimping Tool Illustration Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070 19 EXPLODED...
  • Page 9 RK6040 60-ton, Single-acting, Die-type Crimping Tool Parts List—RK6040 Part No. 501 0566.3 501 0567.1 501 0568.0 501 0569.8 501 0570.1 501 0571.0 501 0572.8 501 0573.6 501 0574.4 501 0576.0 501 0577.9 501 0578.7 501 0579.5 501 0580.9 501 0581.7 501 0584.1...
  • Page 10 Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Drive, Rockford, IL 61109-2988 USA Customer Service (International): 815/397-7070 • Fax: 815/397-9247 Customer Service (North America): 800/435-0786 • USA Fax: 800/451-2632, 815/397-1865 Canada Fax: 800/524-2853 www.greenlee.textron.com Printed in the USA...
