The sand filter removes suspended particles but does not sanitize your pond.
Pond chemistry is a specialized area and you should consult your local pond
service specialist for details.
Power:
Wattage:
Maximum working pressure:
Effective filtering area:
Maximum Flow Rate:
Recommended filtering media:
(Not included)
Recommended filtering media quantity: No. 20 silica sand 45 Kg (100 Lbs) or glass sand
Limited Warranty:
NOTE: NOT SUITABLE FOR USE WITH KCP-LOW -SALT AUTOMATIC SALTWATER
SYSTEM (MODEL 6110/6220)
TOOLS REQUIRED:
Pump location and mounting:
•
The system must be installed on a solid level and vibration-free base.
•
Provide a location protected from the weather, moisture, flooding and
freezing temperature.
•
Provide adequate access, space and lighting for routine maintenance.
•
Pump motor requires free circulation of air for cooling. Do not install
the pump in a damp or non-ventilated location.
A team of 2 or more people is recommended for setting up this product.
Motor pre-filtering assembly setup:
1.
Remove the sand filter and its accessories
from the packaging carefully and inspect for
any visible damage. If parts are damaged
contact your local service center listed at
the back of this owner's manual.
2.
In a counter-clockwise motion unscrew the
leaf trap cover (14) from the pre-filter
housing. Take out the basket (16) and filter
housing nut (17) (see drawing 1).
3.
Connect the pre-filter housing to the motor
water inlet. Note: Align the connector in the
pre-filter housing with the water inlet on the
motor (see drawing 2).
SAVE THESE INSTRUCTIONS
(128GS) MODEL SF20220R SAND FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 10/28/2011
PRODUCT SPECIFICATIONS
220-240 Volt AC
650 W
3.5 bar (50 psi)
0.13 m
10030 liters/hour (2650 gallons/hour)
No. 20 silica sand or glass sand. Particle size
range 0.45 to 0.85 mm (0.018 to 0.033 inches).
Uniformity Coefficient less than 1.75.
32 Kg (70 Lbs).
see "Limited Warranty"
SETUP INSTRUCTIONS
One (1) Phillips screwdriver
2
(1.44 ft
2
)
14
35
16
17
128
English
GS
1
2
