Intex SP20220 Owner's Manual page 7

Before assembling your product, please take a few minutes to check the contents
REF. NO.
1
PRESSURE GAUGE
2
6-WAY VALVE
3 DRAIN OUTLET COVER
4
CLAMP
5
TANK O-RING
6
SAND SHIELD
7
CENTER PIPE HUB
8
LATERAL
9
DRAIN VALVE CAP
10
DRAIN VALVE O-RING
11
L-SHAPE O-RING
12 HOSE WITH NUTS
13
SAND FILTER INTERCONNECTING HOSE
14 LEAF TRAP NUT
15 LEAF TRAP O-RING
16 BASKET
17 FILTER HOUSING NUT
18
L-SHAPE O-RING
19 SEDIMENT RELEASE VALVE
20 VALVE O-RING
21 PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
22
HOSE O-RING
23
STEP WASHER
24
STRAINER NUT
25
FLAT STRAINER RUBBER WASHER
26
THREADED STRAINER CONNECTOR
27
ADJUSTABLE POOL INLET NOZZLE
28
ADAPTOR B
29
STRAINER CONNECTOR (
30
POOL INLET NOZZLE (
31
STRAINER GRID (
32
SCREW
33
PUMP MOTOR & CONTROL
34
PRE-FILTER ASSEMBLY
35 LEAF TRAP COVER
36 SAND FILTER PUMP MOTOR INLET O-RING
37 16" SAND FILTER PUMP AND COMBO TANK
38 16" SAND FILTER PUMP TANK BASE
When ordering parts, be sure to quote the model number and part numbers.
SAVE THESE INSTRUCTIONS
(128GS) MODEL SF20220R SAND FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 10/28/2011
PARTS REFERENCE (continued)
and become familiar with all the parts.
DESCRIPTION
Optional)
Optional)
Optional)
English
SPARE PART
QTY.
NO.
1 11224
1 11496
1 11131
1 11380
1 11379
1 11382
1 11495
10 11384
1 11456
1 11385
4 11228
2 11010
1 11535
1 11479
1 11232
1 11260
1 11261
1 11412
1 10460
1 10264
2 10747
2 10262
2 10745
2 10256
2 10255
2 11235
1 11074
2 10722
2 11070
1 11071
1 11072
2 11381
1 11322
1 11371
1 11480
2 11457
1 11497
1 11514
