Summary of Contents for ASUSTOR AS3102T v2
- Page 1 Quick Installation Guide Applicable Models: AS3102T/AS3102T v2/AS3104T /AS3202T/AS3204T/AS3204T v2 Ver.2.3.0903 (2015-3-2) Ver.3.2.0117(2019-01-17)
-
Page 2: Table Of Contents
Table of Contents Notices ............................ 3 Safety Precautions ........................4 1. Package Contents ......................5 2. Optional Accessories ......................7 3. Hardware Installation Guide ....................8 Tools Needed for Hard Disk Installation ................8 Hard Disk Installation ......................8 Securing the Power Cord....................13 Connecting and Powering on the NAS ................ -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Safety Precautions
Safety Precautions The following safety precautions will increase the life of the NAS. Follow all precautions and instructions. Electrical Safety Unplug this product from the power source before cleaning. Use only the bundled power adapter. Using other power adapters may damage your device. Ensure that you plug the power adapter to the correct power input rating. -
Page 5: Package Contents
1. Package Contents Applicable Models: AS3102T, AS3102T v2, AS3202T, AS3104T, AS3204T, AS3204T v2 Model Name AS3102T/AS3102T v2/AS3202T AS3104T/AS3204T/AS3204T v2 Power Cord Adapter AS3102T/ AS3104T/ AS3102T v2 AS3204T v2 AS3202T AS3204T RJ45 Network Cable Power Cord Bracket Screws for use with 3.5”... - Page 6 Quick Installation Guide...
-
Page 7: Optional Accessories
2. Optional Accessories The items below may be purchased from the ASUSTOR Accessories Store http://shop.asustor.com. -
Page 8: Hardware Installation Guide
Hard Disk Installation Remove the screws from the rear of the NAS as shown in the graphic below. AS3102T/AS3102T v2/AS3202T AS3104T/AS3204T/AS3204T v2 Place the device sideways on a flat surface. Note the wording indicating the directions for opening and... - Page 9 AS3102T/AS3102T v2/AS3202T AS3104T/AS3204T/AS3204T v2 Installing 3.5 inch hard disks: Slide the hard disks all the way into the disk bay until they are firmly seated and connected with the SATA connector. For 3.5” drives with 3 screw holes on each side.
- Page 10 AS3102T/AS3102T v2/AS3202T AS3104T/AS3204T/AS3204T v2 Note: Please insert the hard disk into the HDD 1 slot shown in the graphic in order to have it initialized. For 3.5” drives with 2 screw holes on each side. AS3102T/AS3102T v2/AS3202T...
- Page 11 Secure each hard disk with the screws provided as shown in the graphic below. For 3.5” drives with 3 screw holes on each side. AS3102T/AS3102T v2/AS3202T Note: If you wish to utilize the RAID function, it is recommended that you use hard disks of the same capacity in order to fully utilize the capacity of all hard disks.
- Page 12 Note: If you wish to utilize the RAID function, it is recommended that you use hard disks of the same capacity in order to fully utilize the capacity of all hard disks. Replace the cover and tighten the screws that were removed previously. AS3102T/AS3102T v2/AS3202T AS3104T/AS3204T/AS3204T v2...
-
Page 13: Securing The Power Cord
Securing the Power Cord Note: You can use the provided cord bracket to secure the power cord in place, if you are concerned about the NAS power cord becoming detached when the NAS is moved. 1. Take the cord bracket out of the accessories box. 2. -
Page 14: Connecting And Powering On The Nas
3. Remove the fan screw by unscrewing it counter-clockwise. AS3102T/AS3102T v2/AS3202T AS3104T/AS3204T/AS3204T v2 4. Position the bracket over the hole for the removed fan screw. Secure the bracket in place by replacing the fan screw. AS3102T/AS3102T v2/AS3202T AS3104T/AS3204T/AS3204T v2 Connecting and Powering on the NAS Connect the NAS to its power supply. - Page 15 Note: If the device has been subjected to strong shaking or shock, it is recommended that you remove the cover to ensure that the hard disks are properly installed and that the screws are properly fastened. AS3102T/AS3102T v2/AS3202T AS3104T/AS3204T/AS3204T v2...
-
Page 16: Software Installation Guide
Download Center Installation Windows Users After ASUSTOR Control Center has been installed, it will automatically begin to scan your network for ASUSTOR NAS devices. Select your NAS from the list and follow the installation wizard’s instructions to complete the configuration... - Page 17 Mac Users After ASUSTOR Control Center has been installed, it will automatically begin to scan your network for ASUSTOR NAS devices. Select your NAS from the list and follow the installation wizard’s instructions to complete the configuration process.
-
Page 18: Web Installation
Web Installation If you already know your NAS’s current IP address, you can open up a web browser and enter in your NAS’s IP address (for example: http://192.168.1.168:8000) to begin initialization. Please follow the instructions from the installation wizard to complete the configuration process. Installation Using a Mobile Device Search for “AiMaster”... - Page 19 AiMaster for Android AiMaster for iOS Make sure that your mobile device is connected to the same local network that your NAS is connected to. Next, open AiMaster and then select the [ + ] icon from the toolbar at the top of the screen. Select [Auto Discovery].
- Page 20 Select your NAS from the list that appears. Select [Start Initialization] to begin installation. Follow the prompts and instructions to complete the configuration process.
-
Page 21: Installation Using A Direct Connection
Installation Using a Direct Connection Troubleshooting Please see section for installation instructions. Shutting Down Your NAS 1. Confirm the function settings for the power button as shown in the graphic below. When the power button is held down for 1.5 seconds you can decide whether to shut down the NAS or have it enter into sleep mode. - Page 22 2. Hold down the power button for 1.5 seconds. You should be able to hear a “beep” from the system buzzer. Let go of the power button and the NAS will either shut down or enter sleep mode depending on your configuration.
-
Page 23: Appendix
5.Appendix LED Indicators AS3102T/AS3102T v2/AS3104T/AS3202T/AS3204T/AS3204T v2 1. Power LED Indicator 2. System Status LED Indicator 3. Network LED Indicator 4. Hard Disk LED Indicator Color Description State Indicator Yellow Steadily lit Power on Power Orange Flashes every 10 seconds LED night mode Flashing Powering on Yellow... -
Page 24: Rear Panel
1. Power Button 2. Reset Button 3. USB 3.0 Port 4. HDMI Port 5. Network Port 6. DC Input 7. K-Lock 8. System Fan AS31XXT v2/AS32XXT v2 Troubleshooting Q: Why can’t I detect my ASUSTOR NAS using ASUSTOR Control Center? - Page 25 A: If you are having trouble detecting your NAS using ASUSTOR Control Center, please do the following: 1. Please check your network connection: Make sure that your computer and your NAS are part of the same local area network. Check to see if the network LED indicator is lit. If you find that it is not lit, try connecting your Ethernet cable to the other network port or try using a different Ethernet cable.
- Page 26 Right-click on [Local Area Connection] and select [Properties]. Under the [Networking] tab select [Internet Protocol Version 4 (TCP/IPv4)] and click on [Properties].
- Page 27 Under the [General] tab select the [Use the following IP address] radio button. Set the [IP address] to 169.254.1.1 and the [Subnet mask] to 255.255.0.0 and then click on [OK]. Open up ASUSTOR Control Center to scan for your NAS.
- Page 28 4. If the above mentioned procedures have not managed to solve your problem, please contact your local ASUSTOR dealer or ASUSTOR Customer Service http://support.asustor.com.You are also encouraged ASUSTOR Knowledgebase. to browse through the...
