INSTALLATION CLEARANCES

Left
side
> 4 n i 1 ( c 0 m )
Ceiling opening size
Maintenance space

MAINTENANCE CLEARANCES

Bottom Return
Blower/Motor Service Clearance
Filter Service Clearance
Capacity (Kbtu)
NOTE: If installed above a hard lid ceiling, utilize a ceiling access panel the length and width of the unit, otherwise the blower components and/or
entire unit cannot be removed.
If a single access panel is desired, the minimum dimensions should be:
S
Width: The width of the unit plus 2−inches on both sides
S
Length: The length of the unit plus 18−inches on the connection end and 2−inches on the opposite end
32801000302
Strong and durable ceiling
Indoor unit
> 1 1 8 . n i 3 ( c 0
Fig. 6 - Installation Clearances
Width of the Unit
Unit
B
Service access
Fig. 7 - Maintenance Clearances
Table 5—Maintenance Clearances
9K
12K
18K
24K
36K
48K
58K
Specifications subject to change without notice.
>0.8in(2cm)
Right
side
Access Panel
Service access
m )
Service access
7.8 in (20cm)
>11.8in（30cm）
Blower/Motor Service Clearance
PCB Board Service Clearance
>
11.8in(30cm)
>
0.8in(2cm)
Ceiling opening size
Ceiling
Floor
Coil Connection Area
Condensate Drain Piping Area
Condensate Pump Service Clearance
Sensor Service Clearance
Access Panel
17.7 in (45cm) x 17.7 in (45cm)
B
11.81in.(30cm)
11.81in.(30cm)
11.81in.(30cm)
11.81in.(30cm)
11.81in.(30cm)
15.75in.(40cm)
15.75in.(40cm)
