Installation Guide
10BASE-T/10BASE-FL
Ethernet Media Converter
KC-10TF SERIES
DOC. 000830-KC10TF-K Rev.1.0
P/N: 750-0145-001
General Description
Specifications
o
Connectors & Cables
10BASE-T RJ-45 Connectors (TP Port)
RJ-45 Pin MDI-X Jack
MDI Jack
1
Rx+
2
RX-
3
Tx+
6
Tx-
10BASE-T UTP Cable
Fiber Optic Connector (Fiber Port)
Models
Model
KC-10TF/T
KC-10TF/C
KC-10TF/S
* Cable length : the maximum length in point-to-point full duplex
operation
Tx+
Tx-
Rx+
Rx-
62.5/125µm
9/125µm
Connector
Cable Used Cable Length*
ST
MM
SC
MM
ST
SM
2Km
2Km
14Km
