Page 1
USER GUIDE A commitment to: Belling Gas Range Part Number: 083595902 Date: 28/03/17...
Page 2
NZ - New Zealand DE - Germany NL - Netherlands AU - Australia ES - Spain To contact Belling about your appliance, please call: Warranty Registration Customer Care Helpline 0344 815 3746 0800 952 1068 In case of difficulty within the UK...
Page 3
INTRODUCTION Thank you for buying this British-built appliance from us. This user guide book is designed to help you through each step of owning your new product. Please read it carefully before you start using your appliance, as we have endeavored to answer as many questions as possible, and provide you with as much support as we can.
Page 4
SAFETY WARNING • During use the appliance becomes hot. Care should be taken to avoid touching heating elements. • The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
Page 5
• Accessible parts may become hot when the grill is in use. Children should be kept away. • If the cooker is placed on a base, measures have to be taken to prevent the appliance slipping from the base. CAUTION •...
Page 6
• The appliance must never be disconnected from the mains supply during use, as this will seriously affect the safety and performance, particularly in relation to surface temperatures becoming hot and gas operated parts not working efficiently. The cooling fan (if fitted) is designed to run on after the control knob has been switched off.
USING YOUR APPLIANCE Getting to know your product Note: Your appliance layout may differ depending on the model. Small Medium Medium Centre back Left hand rear Right hand rear (if fitted) Large Medium Small Left hand front Centre front Right hand front Control Panel 90cm Thermostat indicator Cook zones...
Control Panel 100/110cm Clock/Programmer Cook zones Cook zones Grill Oven Oven Light Hob and Oven Light Switch controls Ignition Switch Appliance functions Note: Your oven may not have all of the functions shown here. We recommend for best cooking results, please preheat your oven for 15 minutes and 3-5 minutes for grilling.
Page 9
Gas Oven Electric oven (90cm only) Hob/Grill Oven/Grill Some appliances are automatic ignition and do not have an ignition switch fitted. When the grill is switched on, the cooling fans switch on after a few minutes to keep the fascia and control knobs cool during cooking/grilling. The cooling fans may operate when the main ovens are in use, depending on the temperature setting.
Page 10
Tall fanned oven (90cm only) Choose required setting The red thermostat indicator light (if fitted) will come on until the selected temperature has reached. Grill THE DOOR MUST BE OPEN WHEN THE GRILL IS USED FOR CONVENTIONAL GRILLING. Grill pan, trivet and detachable grill pan handle The grill trivet (inside the grill pan) can be inverted to give a high or low position, or it may be removed.
• Hold the control knob and press the ignition in for up to 15 seconds then release. For the wok (if fit- ted), please allow the burner to warm up for a few minutes. • Once lit, turn the control knob to the required setting. If the burner fails to ignite within this time, release the control knob and wait 1 minute before attempting to re-ignite.
Please be aware that only the main oven is controlled by the programmer. Clock / Programmer Note: Your clock / programmer may not have all these functions Minus Menu Plus Minute minder Manual mode Volume level Cooking time / Duration 7-segment display End of cooking time Max.
Setting the time of day By pressing menu, scroll through the functions until you reach ‘time of day’. Press the function button until the ‘time of day’ Press the plus or minus buttons to set a time symbol appears Setting the minute minder The maximum cooking time that can be set is 99 minutes.
Page 14
To modify or cancel the minute minder Return to the minute minder function and use either the plus or minus buttons to adjust the time. By setting the time to ‘0.00’, this will cancel the countdown. Setting the cooking time (the duration of time the oven will operate for) Semi Auto- matic cooking The maximum cooking time that can be set is 23 hours and 59 minutes.
Page 15
Setting the end of cooking time (to set a time for the oven to turn off) Fully Auto- matic Enter cooking duration as described in ‘Setting the cooking time’ section. The display shows the current ‘time of day’ plus the ‘end of cooking time’ symbol. The latest ‘end of cooking time’...
Setting the volume Press the menu button until “LX” (X = 1, 2 or 3) flashes on the display. Use the plus or minus buttons to select a tone. Note: Default tone is L3 Activating / deactivating Key lock Press and hold the plus button for 3-5 seconds Once the Key lock is active, the buttons will be inactive.
Page 17
Removing Shelf Runners Telescopic positions Telescopic positions (if fitted) (if fitted) Standard shelves Slightly raise the shelf and insert in the chosen shelf position Ensure the shelf is fully pushed back towards the back of the oven, until the shelf stopper is reached.
Removing Telescopic shelves (if fitted) Grasp and lift shelf Lift shelf from the retaining tabs. Front of appliance Before removing the shelves completely, please make sure that the shelf is unclipped from the retaining tabs. Changing the light bulb Not all appliances have the same number and type of bulbs. Before you replace your bulb, check to see what type you have.
Page 19
If required, the wok ring should be located on top of the pan supports. The locating cutouts on the bot- tom of the wok ring engage with the four fingers of the pan supports around the centre burner location. Ensure the wok ring is located correctly, is fully engaged with the pan support fingers and is not able to rotate or slide across the pan supports before use.
CLEANING YOUR APPLIANCE Do’s Note: Always switch off your appliance and allow it to cool down before you clean any part of it. Note: Please take extra care when cleaning over the symbols on the control panel, as this can lead to them fading.
Page 21
Please keep this handbook for future reference, or for anyone else who may use the appliance.
Page 22
Please keep this handbook for future reference, or for anyone else who may use the appliance.
Page 23
Please keep this handbook for future reference, or for anyone else who may use the appliance.
TECHNICAL DATA Gas - range Databadge Lower part of the front frame Appliance class Class 1 - freestanding cooker Type of gas See the databadge for specific gas type Gas category Natural Gas I2H & LP Gas I3+ Gas pressure settings G20 Natural gas @ 20 mbar G30 Butane @ 28-30mbar G31 Propane @ 37mbar Pressure test point...
